| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 6164-12-6411 | MUFFLER | 10040- | |
| (\2\6164-12-6410) | MUFFLER | (10040-10435) | ||
| 2 | 6164-12-6540 | PLATE | 10040- | |
| 3 | 6164-12-6420 | BRACKET | 10040- | |
| 4 | 01010-31235 | BOLT | 10040- | |
| 5 | 01641-01223 | WASHER | 10040- | |
| 6 | 6164-12-6430 | BAND | 10040- | |
| 7 | 01580-01613 | NUT | 10040- | |
| 8 | 01641-01626 | WASHER | 10040- | |
| 9 | 6164-12-6510 | CONNECTOR | 10040- | |
| 10 | 6164-12-6480 | GASKET (K1) | 10040- | |
| 11 | 01050-61250 | BOLT | 10040- | |
| 12 | 6128-81-2920 | NUT | 10040- | |
| 13 | 6164-12-6530 | BRACKET | 10040- | |
| 14 | 6164-12-6520 | BRACKET | 10040- | |
| 15 | 01010-61025 | BOLT | 10040- | |
| 16 | 01010-61025 | BOLT | 10040- | |
| 17 | 01641-01016 | WASHER | 10040- | |
| 18 | 6164-12-6570 | COVER | 10040- | |
| 19 | 6164-12-6580 | COVER | 10040- | |
| 20 | 6164-12-6470 | COVER | 10040- | |
| 21 | 6164-12-6490 | COVER | 10040- | |
| 22 | 6164-12-5310 | BOLT | 10251- | |
| \0\01010-31016 | BOLT | 10040-10250 | ||
| 23 | 01640-01016 | WASHER | 10251- | |
| \0\01641-01016 | WASHER | 10040-10250 | ||
| 24 | 01580-01008 | NUT | 10040- | |
| 25 | 01010-61020 | BOLT | 10040- | |
| 26 | 6164-12-6440 | TUBE | 10040- | |
| 27 | 6991-11-5990 | CLAMP | 10040- | |
| 28 | 01010-31016 | BOLT | 10040- | |
| 29 | 6131-12-5920 | SPACER | 10040- | |
| 30 | 01641-01016 | WASHER | 10040- | |
| 31 | 01010-31040 | BOLT | 10040- | |
| 6162-13-5302 | VALVE ASS'Y | 10040- | ||
| 32 | \6\ | BODY | 10040- | |
| 33 | \6\ | VALVE | 10040- | |
| 34 | \6\ | SEAT | 10040- | |
| 35 | 6164-12-6450 | PIPE | 10040- | |
| 36 | 6162-13-5610 | GASKET (K1) | 10040- | |
| 37 | 01020-01030 | BOLT | 10040- | |
| 38 | 01020-01035 | BOLT | 10040- | |
| 39 | 01641-01016 | WASHER | 10040- | |
| 40 | 01580-31008 | NUT | 10040- | |
| 41 | 6164-12-5470 | CLAMP | 10040- | |
| 42 | 01010-31030 | BOLT | 10040- | |
| 43 | 01641-01016 | WASHER | 10040- | |
| 44 | 01580-31008 | NUT | 10040- | |
| 45 | 6164-12-6550 | PLATE | 10040- | |
| 46 | 6164-12-6560 | BRACKET | 10040- | |
| 47 | 01010-31025 | BOLT | 10040- | |
| 48 | 01010-31035 | BOLT | 10040- | |
| 49 | 01010-31030 | BOLT | 10040- | |
| 50 | 01643-31032 | WASHER | 10040- | |
| 51 | 01580-01008 | NUT | 10040- |
