| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 144-49-13634 | TUBE | 22388- | |
| 144-49-13633 | TUBE | 20054-22387 | ||
| 144-49-13632 | TUBE | 20024-20053 | ||
| 144-49-13631 | TUBE | 20006-20021 | ||
| 2 | 07000-03025 | O-RING | 20006- | |
| 3 | 01010-31080 | BOLT | 20006- | |
| 4 | 01602-01030 | WASHER | 20006- | |
| 5 | 07102-20504 | HOSE | 22388- | |
| 07102-00504 | HOSE | 20006-22387 | ||
| 6 | 144-49-13415 | TUBE | 22388- | |
| 144-49-13414 | TUBE | 20024-22387 | ||
| 144-49-13413 | TUBE | 20006-20021 | ||
| 7 | 144-49-18313 | TUBE | 20024- | |
| 144-49-18312 | TUBE | 20006-20021 | ||
| 8 | 144-49-18323 | TUBE | 20024- | |
| 144-49-18322 | TUBE | 20006-20021 | ||
| 9 | 07000-03025 | O-RING | 20006- | |
| 10 | 01010-31030 | BOLT | 20006- | |
| 11 | 01602-01030 | WASHER | 20006- | |
| 12 | 07000-03035 | O-RING | 20006- | |
| 13 | 01010-31235 | BOLT | 20006- | |
| 14 | 01602-01236 | WASHER | 20006- | |
| 15 | 144-49-13376 | TUBE | 22388- | |
| 144-49-13375 | TUBE | 20032-22387 | ||
| 144-49-13374 | TUBE | 20024-20031 | ||
| 144-49-13373 | TUBE | 20006-20021 | ||
| 16 | 144-49-18414 | TUBE | 22388- | |
| 144-49-18413 | TUBE | 20054-22387 | ||
| 144-49-18412 | TUBE | 20024-20053 | ||
| 144-49-18411 | TUBE | 20006-20021 | ||
| 17 | 07000-03025 | O-RING | 20006- | |
| 18 | 144-49-13690 | ORIFICE | 20006-20021 | |
| 19 | 144-49-13671 | SPACER | 20024- | |
| 144-49-13670 | SPACER | 20006-20021 | ||
| 20 | 144-49-13680 | GASKET | 20006- | |
| 21 | 01010-31075 | BOLT | 20024- | |
| 01010-31055 | BOLT | 20006-20021 | ||
| 22 | 01602-01030 | WASHER | 20006- | |
| 23 | 144-49-18352 | TUBE | 22388- | |
| 144-49-18351 | TUBE | 20006-22387 | ||
| 24 | 07000-03025 | O-RING | 20006- | |
| 25 | 01010-31030 | BOLT | 20006- | |
| 26 | 01602-01030 | WASHER | 20006- | |
| 27 | 07102-20504 | HOSE | 22388- | |
| 07102-00504 | HOSE | 20006-22387 | ||
| 28 | 144-49-18283 | TUBE | 22388- | |
| 144-49-18282 | TUBE | 20024-22387 | ||
| 144-49-18281 | TUBE | 20006-20021 | ||
| 29 | 07000-03022 | O-RING | 20032- | |
| 07000-03025 | O-RING | 20006-20031 | ||
| 30 | 01010-31065 | BOLT | 20054- | |
| 01040-31050 | BOLT | 20006-20053 | ||
| 31 | 01602-01030 | WASHER | 20006- | |
| 32 | 144-49-18550 | BRACKET | 20006- | |
| 33 | 01010-31020 | BOLT | 20006- | |
| 34 | 01602-01230 | WASHER | 20006- | |
| 35 | 01643-31232 | WASHER | 20006- | |
| 36 | 144-49-18560 | PLATE | 20006- | |
| 37 | 01010-31020 | BOLT | 20006- | |
| 38 | 01602-01030 | WASHER | 20006- | |
| 39 | 01643-31032 | WASHER | 20054- | |
| 40 | 144-49-13462 | BRACKET | 20032- | |
| 144-49-13461 | BRACKET | 20006-20031 | ||
| 41 | 07283-02236 | CLIP | 20006- | |
| 42 | 01599-01011 | NUT | 20006- | |
| 43 | 01643-31032 | WASHER | 20006- | |
| 44 | 144-49-13491 | PLATE | 20024- | |
| 144-49-13490 | PLATE | 20006-20021 | ||
| 45 | 144-49-13472 | CLAMP | 22388- | |
| 144-49-13471 | CLAMP | 20006-22387 | ||
| 46 | 01010-31230 | BOLT | 20006- | |
| 47 | 01602-01236 | WASHER | 20006- | |
| 48 | 144-49-13950 | BRACKET | 23283- | |
| \3\144-49-13484 | BRACKET | 22388-23282 | ||
| (144-49-13950{01010-31065(2))} | ||||
| 144-49-13483 | BRACKET | 20024-22387 | ||
| 144-49-13482 | BRACKET | 20006-20021 | ||
| 49 | 01010-31065 | BOLT | 23283- | |
| 01010-31050 | BOLT | 20006-23282 | ||
| 50 | 01602-01030 | WASHER | 20006- | |
| 51 | 07283-02236 | CLIP | 20006- | |
| 52 | 01599-01011 | NUT | 20006- | |
| 53 | 01643-31032 | WASHER | 20006- |
