| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 257-85-12501 | PUMP ASS'Y | 1001- | |
| 2 | 258-85-14810 | BRACKET | 1001- | |
| 3 | 266-58-76300 | PIPE | 1001- | |
| 4 | 258-80-14640 | NIPPLE | 1001- | |
| 5 | 07280-02323 | CLAMP | 1001- | |
| 6 | 258-80-26420 | NOZZLE | 1001- | |
| 7 | 266-15-11004 | PLUG | 1001- | |
| 8 | 267-19-15100 | HOSE | 1001- | |
| 9 | 267-19-15300 | HOSE | 1001- | |
| 10 | 01010-50820 | BOLT | 1001- | |
| 11 | 01010-50820 | BOLT | 1001- | |
| 12 | 01643-20823 | WASHER | 1001- | |
| 13 | 01220-40612 | SCREW | 1001- | |
| 14 | 01602-20619 | WASHER,SPRING | 1001- | |
| 15 | 01602-20825 | WASHER,SPRING | 1001- | |
| 16 | 258-80-26410 | VALVE | 1001- | |
| 17 | 267-11-12001 | NIPPLE | 1001- | |
| 18 | 258-07-01203 | ELBOW | 1001- | |
| 19 | 267-11-51015 | NIPPLE | 1001- | |
| 20 | 258-85-14710 | VALVE | 1001- | |
| 21 | 266-52-76800 | HARNESS | 1001- | |
| 22 | 258-06-12110 | TUBE | 1001- | |
| 23 | 258-80-14640 | NIPPLE | 1001- | |
| 24 | 257-20-17550 | VALVE | 1001- | |
| 25 | 257-80-15610 | NIPPLE | 1001- | |
| 26 | 07325-00100 | NIPPLE | 1001- | |
| 27 | 258-20-27421 | ELBOW | 1001- | |
| 28 | 07324-00100 | TEE | 1001- | |
| 29 | 07281-00137 | CLAMP | 1001- | |
| 30 | 258-85-14820 | HOSE | 1001- |
