| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 257-20-17550 | VALVE | 1272-1321 | |
| 1 | 265-98-12001 | ELBOW | 1201-1271 | |
| 2 | 258-80-46210 | NIPPLE | 1272-1321 | |
| 2 | 258-70-23770 | BUSHING | 1201-1271 | |
| 3 | 266-58-86620 | HOSE | 1201-1321 | |
| 4 | 07281-10137 | CLAMP | 1201-@ | |
| 5 | 257-80-15610 | NIPPLE | 1201-1321 | |
| 6 | 258-80-36100 | PUMP ASS'Y | 1201-@ | |
| 7 | 01220-40616 | SCREW | 1201-@ | |
| 8 | 01602-20619 | WASHER,SPRING | 1201-@ | |
| 9 | 266-58-86610 | BRACKET | 1201-@ | |
| 10 | 01010-80816 | BOLT | 1201-@ | |
| 11 | 01602-20825 | WASHER,SPRING | 1201-@ | |
| 12 | 265-98-12001 | ELBOW | 1201-@ | |
| 13 | 07324-00100 | TEE | 1201-@ | |
| 14 | 07325-00100 | NIPPLE | 1201-@ | |
| 15 | 07325-00100 | NIPPLE | 1201-@ | |
| 16 | 257-20-17550 | VALVE | 1201-@ | |
| 17 | 266-80-76420 | HOSE | 1201-@ | |
| 18 | 257-80-15610 | NIPPLE | 1201-@ | |
| 19 | 07281-10137 | CLAMP | 1201-@ | |
| 20 | 258-20-27530 | HOSE | 1201-@ | |
| 21 | 07281-10137 | CLAMP | 1201-@ | |
| 22 | 257-80-15610 | NIPPLE | 1201-@ | |
| 23 | 258-80-26410 | VALVE | 1201-@ | |
| 24 | 07325-00100 | NIPPLE | 1201-@ | |
| 25 | 266-58-86310 | PIPE | 1201-@ | |
| 26 | 258-80-26420 | NOZZLE | 1201-@ | |
| 27 | 258-85-14710 | VALVE | 1201-@ | |
| 28 | 266-15-11004 | PLUG | 1201-@ | |
| 29 | 07283-22236 | CLIP | 1201-@ | |
| 30 | 01599-01011 | NUT | 1201-@ |
