| Item | Part No. | Part Name | Qty | Serial No. |
| (415-924-1002) | OPERATOR'S CAB ASS'Y | 12001- | ||
| (415-924-1001) | OPERATOR'S CAB ASS'Y | ..-11999 | ||
| (415-924-1000) | OPERATOR'S CAB ASS'Y | 10001-.. | ||
| THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.8041 TO 8049. | ||||
| (415-54-16004) | DOOR ASS'Y,L.H. | 12001- | ||
| (415-54-16003) | DOOR ASS'Y,L.H. | ...-11999 | ||
| (415-54-16002) | DOOR ASS'Y,L.H. | .-... | ||
| (\0\415-54-16001) | DOOR ASS'Y,L.H. | 10001-. | ||
| (415-54-17004) | DOOR ASS'Y,R.H. | 12001- | ||
| (415-54-17003) | DOOR ASS'Y,R.H. | ...-11999 | ||
| (415-54-17002) | DOOR ASS'Y,R.H. | .-... | ||
| (\0\415-54-17001) | DOOR ASS'Y,R.H. | 10001-. | ||
| THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.8047 TO 8048. | ||||
| 1 | 419-54-16620 | HANDLE,OUTER | 10001- | |
| 2 | 01224-40416 | SCREW | 10001- | |
| 2A | 419-923-1860 | WASHER | 12001- | |
| 3 | 419-54-16680 | COVER,L.H. | 10001- | |
| 419-54-17330 | COVER,R.H. | 10001- | ||
| 4 | 01435-00612 | BOLT | 12001- | |
| \0\421-54-16850 | BOLT | 10001-11999 | ||
| 5 | 419-54-16651 | ROD | 10001- | |
| 6 | 421-54-16350 | SPRING | 10001- | |
| 7 | 421-54-16370 | PIN | 10001- | |
| 8 | 419-54-16671 | LEVER | 10001- | |
| 9 | 01641-20608 | WASHER | 10001- | |
| 10 | 01580-10605 | NUT | 10001- | |
| 11 | 419-54-16641 | ROD | 10001- | |
| 12 | 421-54-16350 | SPRING | 10001- | |
| 13 | 421-54-16370 | PIN | 10001- | |
| 14 | 421-54-16201 | LOCK,R.H. | 10001- | |
| 421-54-17201 | LOCK,L.H. | 10001- | ||
| 15 | 01224-40616 | SCREW | 10001- | |
| 16 | 421-54-16440 | WASHER | 10001- | |
| 17 | 01435-00612 | BOLT | 12001- | |
| \0\421-54-16850 | BOLT | 10001-11999 | ||
| 18 | 419-54-16651 | ROD | 10001- | |
| 19 | 421-54-16350 | SPRING | 10001- | |
| 20 | 421-54-16370 | PIN | 10001- | |
| 21 | 419-54-16671 | LEVER | 10001- | |
| 22 | 01641-20608 | WASHER | 10001- | |
| 23 | 01580-10605 | NUT | 10001- | |
| 24 | 419-54-16740 | ROD | 10001- | |
| 25 | 425-54-16450 | SPRING | 10001- | |
| 26 | 425-54-16460 | PIN | 10001- | |
| 27 | 425-54-16420 | HANDLE,L.H. | 10001- | |
| 425-54-17420 | HANDLE,R.H. | 10001- | ||
| 28 | 01435-00612 | BOLT | 12001- | |
| \0\421-54-16850 | BOLT | 10001-11999 | ||
| 29 | 425-54-16430 | COVER,L.H. | 10001- | |
| 425-54-17430 | COVER,R.H. | 10001- | ||
| 30 | 01225-40512 | SCREW | 10001- |
