| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 01010-81220 | BOLT | K50854- | |
| 2 | 01643-31232 | WASHER | K50854- | |
| 3 | 21M-62-15440 | CLIP | K50854- | |
| 4 | 04434-53412 | CLIP | K50854- | |
| 5 | 20Y-06-81750 | COVER | K50854- | |
| 6 | 01010-81220 | BOLT | K50854- | |
| 7 | 01643-31232 | WASHER | K50854- | |
| 8 | 01010-81025 | BOLT | K50854- | |
| 9 | 01643-31032 | WASHER | K50854- | |
| 10 | 04435-51712 | CLIP | K50854- | |
| 11 | 01010-81225 | BOLT | K50854- | |
| 12 | 01643-31232 | WASHER | K50854- | |
| 206-62-KA791 | HOSE A. (ATT 1 PPC) | K50854- | ||
| 13 | 02760-00229 | HOSE | K50854- | |
| 14 | 20Y-62-22810 | BAND (YELLOW) | K50854- | |
| 15 | 02760-00229 | HOSE | K50854- | |
| 16 | 20Y-62-52330 | HOSE | K50854- | |
| 17 | 20Y-62-22790 | BAND (RED) | K50854- | |
| 18 | 208-62-72480 | HOSE | K50854- | |
| 19 | 20Y-62-22820 | BAND (BLUE) | K50854- | |
| 20 | 08034-20519 | BAND | K50854- | |
| 21 | 206-06-KA151 | HARNESS | K50854- | |
| 22 | 206-810-KA10 | HOSE (A/C) | K50854- | |
| 23 | 206-810-KA20 | HOSE (A/C) | K50854- | |
| 24 | 206-810-KA30 | HOSE (A/C HEATER) | K50854- | |
| 25 | 206-810-KA40 | HOSE (A/C HEATER) | K50854- | |
| 206-62-KA610 | HOSE A. (P, T) | K50854- | ||
| 26 | 206-62-KA620 | HOSE | K50854- | |
| 27 | 206-62-KA630 | HOSE | K50854- | |
| 28 | 20Y-62-22790 | BAND (RED) | K50854- | |
| 206-62-KA641 | HOSE A. (TRAVEL PPC) | K50854- | ||
| 29 | 206-62-KA651 | HOSE | K50854- | |
| 30 | 206-62-KA661 | HOSE | K50854- | |
| 31 | 20Y-62-22820 | BAND (BLUE) | K50854- | |
| 32 | 206-62-KA671 | HOSE | K50854- | |
| 33 | 20Y-62-22850 | BAND (GREEN) | K50854- | |
| 34 | 206-62-KA681 | HOSE | K50854- | |
| 35 | 20Y-62-22790 | BAND (RED) | K50854- | |
| 36 | 08034-20536 | BAND | K50854- | |
| 206-62-KA690 | HOSE A. (PPC LH) | K50854- | ||
| 37 | 206-62-KA710 | HOSE | K50854- | |
| 38 | 20Y-62-22790 | BAND (RED) | K50854- | |
| 39 | 20Y-62-22810 | BAND (YELLOW) | K50854- | |
| 40 | 206-62-KA720 | HOSE | K50854- | |
| 41 | 20Y-62-22820 | BAND (BLUE) | K50854- | |
| 42 | 20Y-62-53410 | HOSE | K50854- | |
| 43 | 20Y-62-53420 | HOSE | K50854- | |
| 206-62-KA730 | HOSE A. (PPC RH) | K50854- | ||
| 44 | 206-62-KA740 | HOSE | K50854- | |
| 45 | 20Y-62-22830 | BAND (WHITE) | K50854- | |
| 46 | 206-62-KA750 | HOSE | K50854- | |
| 47 | 20Y-62-22840 | BAND (BLACK) | K50854- | |
| 48 | 206-62-KA760 | HOSE | K50854- | |
| 49 | 20Y-62-22850 | BAND (GREEN) | K50854- | |
| 50 | 206-62-KA770 | HOSE | K50854- | |
| 51 | 20Y-62-22860 | BAND (BROWN) | K50854- | |
| 52 | 208-62-72870 | HOSE | K50854- | |
| 53 | 20Y-62-22820 | BAND (BLUE) | K50854- | |
| 54 | 20Y-62-42251 | HOSE | K50854- | |
| 55 | 20Y-62-22790 | BAND (RED) | K50854- | |
| 56 | 04434-52511 | CLIP | K50854- | |
| 57 | 141-06-11220 | CLIP | K50854- | |
| 58 | 01010-81020 | BOLT | K50854- | |
| 59 | 01643-31032 | WASHER | K50854- | |
| 60 | 04434-52110 | CLIP | K50854- | |
| 61 | 01010-81020 | BOLT | K50854- | |
| 62 | 01643-31032 | WASHER | K50854- |
