| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | (702-16-04290) | PILOT VALVE,(SEE FIG. Y1670-21A0) | 300001- | |
| 2 | 22U-54-25660 | SEAL | 300001- | |
| 3 | 20Y-43-41760 | SEAT | 300001- | |
| 4 | 01010-81025 | BOLT | 300001- | |
| 5 | 01643-31032 | WASHER | 300001- | |
| 6 | 01643-31032 | WASHER | 300001- | |
| 7 | 20Y-62-25360 | BRACKET | 300001- | |
| 8 | 01010-D1035 | BOLT | 300001- | |
| 9 | 01643-71032 | WASHER | 300001- | |
| 10 | 207-43-81250 | PEDAL | 300001- | |
| 11 | 01010-D1045 | BOLT | 300001- | |
| 12 | 01643-71032 | WASHER | 300001- | |
| 13 | 22U-54-25541 | PLATE | 300001- | |
| 14 | 01010-81025 | BOLT | 300001- | |
| 15 | 01643-31032 | WASHER | 300001- | |
| 16 | 207-43-81220 | PLATE | 300001- | |
| 17 | 01240-00816 | SCREW | 300001- | |
| 18 | 207-43-81240 | CAP | 300001- | |
| 19 | 20T-910-8660 | NIPPLE | 300001- | |
| 20 | 07000-12011 | O-RING | 300001- | |
| 21 | 20Y-62-52160 | ELBOW | 300001- | |
| 22 | 02896-11008 | O-RING | 300001- | |
| 23 | 07000-12011 | O-RING | 300001- | |
| 24 | 20Y-62-43470 | NIPPLE | 300001- | |
| 25 | 02896-11008 | O-RING | 300001- | |
| 26 | 11Y-62-12140 | NIPPLE | 300001- | |
| 27 | 02896-11008 | O-RING | 300001- | |
| 28 | 07000-12011 | O-RING | 300001- | |
| 29 | 20Y-62-52330 | HOSE, 900MM | 300001- | |
| 30 | 20Y-62-52340 | HOSE, 2650MM | 300001- | |
| 31 | 20Y-62-52350 | HOSE, 3350MM | 300001- | |
| 32 | 208-62-72480 | HOSE, 1080MM | 300001- | |
| 33 | 20Y-62-22790 | BAND, RED | 300001- | |
| 34 | 20Y-62-22810 | BAND, YELLOW | 300001- | |
| 35 | 20Y-62-22820 | BAND, BLUE | 300001- | |
| 36 | 04435-51210 | CLIP | 300001- | |
| 37 | 01583-11408 | NUT | 300001- | |
| 38 | 206-06-61130 | SWITCH | 300001- | |
| 39 | 08193-21012 | CLIP | 300001- | |
| 40 | 08053-01510 | CLIP | 300001- | |
| 41 | 01580-01008 | NUT | 300001- | |
| 42 | 08034-20536 | BAND | 300001- | |
| 43 | 04434-50610 | CLIP | 300001- | |
| 44 | 01580-01008 | NUT | 300001- |
