| Item | Part No. | Part Name | Qty | Serial No. |
| (417-54-15011) | OPERATOR'S CAB ASS'Y | 12001- | ||
| 1 | \6\ | CAB | 12001- | |
| 2 | 01010-51220 | BOLT | 12001- | |
| 3 | 417-54-15450 | GLASS,FRONT | 12001- | |
| 4 | 417-54-15460 | STRIP,WEATHER | 12001- | |
| 5 | 421-54-15430 | NOZZLE,WASHER | 12001- | |
| 6 | 421-54-15440 | HOSE | 12001- | |
| 7 | 419-54-15881 | MOTOR,WIPER | .- | |
| 7 | \3\419-54-15880 | MOTOR,WIPER | 12001-. | |
| (419-54-15881,426-54-15233) | ||||
| 8 | 01010-50616 | BOLT | 12001- | |
| 9 | 01643-30623 | WASHER | 12001- | |
| 10 | 419-54-15821 | COVER | 12001- | |
| 11 | 01220-40512 | SCREW | 12001- | |
| 12 | 01642-20508 | WASHER | 12001- | |
| 13 | 426-54-15233 | ARM,WIPER | .- | |
| 13 | \3\426-54-15232 | ARM,WIPER | 12001-. | |
| (419-54-15881,426-54-15233) | ||||
| 14 | 425-54-15250 | BLADE,WIPER | 12001- | |
| 14 | 425-56-21220 | RUBBER | 12001- | |
| 15 | 419-925-1260 | PLATE | 12001- | |
| 16 | 419-54-15830 | SEAL | 12001- | |
| 17 | 01010-50612 | BOLT | 12001- | |
| 18 | 01643-30623 | WASHER | 12001- | |
| 19 | 09415-01008 | CAP | 12001- | |
| 20 | 01220-40810 | SCREW | 12001- |
