| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 09400-30000 | CUSHION | 28877-30237 | |
| \0\09400-10000 | SEAT | 20013-28876 | ||
| 2 | 01010-30820 | BOLT | 20013-30237 | |
| 3 | 01602-00825 | WASHER | 20013-30237 | |
| 4 | 09401-50000 | CUSHION | 28877-30237 | |
| \0\131-57-41130 | CUSHION | 20013-28876 | ||
| 5 | 01010-30820 | BOLT | 20013-30237 | |
| 6 | 01602-00825 | WASHER | 20013-30237 | |
| 7 | 103-57-11112 | FRAME | 28877-30237 | |
| \0\103-57-11111 | FRAME | 20013-28876 | ||
| 8 | 103-57-11220 | BOX ASS'Y | .- | |
| 103-57-11131 | COVER | 20013-. | ||
| 9 | 01010-30835 | BOLT | .-30237 | |
| 01010-30816 | BOLT | .-30237 | ||
| 01010-30816 | BOLT | 20013-. | ||
| 10 | 01602-00825 | WASHER | 20013-30237 | |
| 11 | 09402-00000 | REST,ARM | 20013-30237 | |
| 12 | 101-57-21112 | BRACKET | 20013-30237 | |
| 13 | 101-57-11184 | BRACKET | 20013-30237 | |
| 14 | 01010-30825 | BOLT | 20013-30237 | |
| 15 | 01602-00825 | WASHER | 20013-30237 | |
| 16 | 01010-31016 | BOLT | 20013-30237 | |
| 17 | 01602-01030 | WASHER | 20013-30237 | |
| 18 | 103-57-11120 | PLATE | 20013-30237 | |
| 19 | 01010-30816 | BOLT | 20013-30237 | |
| 20 | 01602-00825 | WASHER | 20013-30237 | |
| 21 | 103-57-11150 | HOOK | 20013-30237 | |
| 22 | 103-57-11170 | SPRING | 20013-30237 | |
| 23 | 135-43-16270 | PIN | 20013-30237 | |
| 24 | 04050-03015 | PIN | 20013-30237 | |
| 25 | 103-57-11140 | ROD | 20013-30237 | |
| 26 | 09304-00835 | KNOB | 20013-30237 | |
| 27 | 125-57-12140 | SPRING | 20013-30237 | |
| 28 | 103-57-11180 | PLATE | 20013-30237 | |
| 29 | 01010-30825 | BOLT | 20013-30237 | |
| 30 | 01602-00825 | WASHER | 20013-30237 | |
| 31 | 01590-00809 | NUT | 20013-30237 | |
| 32 | 04050-02016 | PIN | 20013-30237 | |
| 33 | 103-57-11190 | LEVER | 20013-30237 | |
| 34 | 103-57-11210 | PIN | 20013-30237 | |
| 35 | 04050-02012 | PIN | 20013-30237 | |
| 36 | 103-57-11161 | FRAME | 20013-30237 | |
| 37 | 01010-31230 | BOLT | 20013-30237 | |
| 38 | 01602-01236 | WASHER | 20013-30237 | |
| 39 | 01643-01232 | WASHER | 20013-30237 | |
| 40 | 101-57-31120 | BOX | 20013-30237 | |
| 41 | 140-57-12190 | PLATE | 20013-30237 | |
| 42 | 01010-31225 | BOLT | 20013-30237 | |
| 43 | 01602-01236 | WASHER | 20013-30237 | |
| 44 | 101-57-11142 | COVER | 20013-30237 | |
| 45 | 01010-31016 | BOLT | 20013-30237 | |
| 46 | 01602-01030 | WASHER | 20013-30237 | |
| 47 | 01643-01032 | WASHER | 20013-30237 | |
| 48 | 01016-31235 | BOLT | 20013-30237 | |
| 49 | 01580-11210 | NUT | 20013-30237 | |
| 50 | 101-57-31210 | LOCK | 20013-30237 | |
| 51 | 09459-01614 | SPRING | 20013-30237 | |
| 52 | 01642-01016 | WASHER | 20013-30237 | |
| 53 | 04050-03015 | PIN | 20013-30237 | |
| 54 | 09989-03046 | BOX | 20013-30237 |
