| Item | Part No. | Part Name | Qty | Serial No. |
| (569-15-01001) | TORQFLOW ASS'Y | 1059- | ||
| \0\569-15-01000 | TORQFLOW ASS'Y | 1002-1058 | ||
| (569-15-00010) | TRANSMISSION ASS'Y | 1002- | ||
| 1 | 569-15-12271 | GEAR | 1002- | |
| 2 | 281-15-12830 | RING | 1002- | |
| 3 | 569-15-12360 | CARRIER | 1002- | |
| 4 | 566-15-12371 | COVER | 1002- | |
| 5 | 01010-51020 | BOLT | 1002- | |
| 6 | 566-15-12490 | LOCK | 1002- | |
| 569-15-00070 | SHAFT ASS'Y | 1002- | ||
| 7 | \6\ | SHAFT | 1002- | |
| 8 | 175-15-11230 | PLUG | 1002- | |
| 9 | 281-15-12841 | RING | 1002- | |
| 10 | 569-15-12860 | RING | 1002- | |
| 11 | 568-15-12810 | RING | 1002- | |
| 12 | 06000-06014 | BEARING | 1002- | |
| 13 | 06000-06217 | BEARING | 1002- | |
| 14 | 566-15-12910 | BEARING | 1002- | |
| 15 | 566-15-12161 | SPACER | 1002- | |
| 16 | 04020-01434 | PIN | 1002- | |
| 17 | 01010-51235 | BOLT | 1002- | |
| 18 | 566-15-12460 | LOCK | 1002- | |
| 19 | 566-15-12480 | LOCK | 1002- | |
| 20 | 566-15-12153 | COUPLING | 1002- | |
| 21 | 569-15-13250 | HOLDER | 1002- | |
| 22 | 07000-05075 | O-RING | 1002- | |
| 23 | 01051-52400 | BOLT | 1002- | |
| 24 | 01643-32460 | WASHER | 1002- | |
| 25 | 569-15-12430 | GEAR | 1002- | |
| 26 | 566-15-12542 | SHAFT | 1002- | |
| 27 | 04260-00635 | BALL | 1002- | |
| 28 | 566-15-12780 | WASHER | 1002- | |
| 29 | 566-15-19130 | BEARING | 1002- | |
| 30 | 569-15-12611 | GEAR | 1002- | |
| 31 | 287-15-12710 | DISC | 1002- | |
| 32 | 287-15-12720 | PLATE | 1002- | |
| 33 | 569-15-12780 | PLATE | 1002- |
