Item | Part No. | Part Name | Qty | Serial No. |
417-22-16103 | PARKING BRAKE ASS'Y | 20001- | ||
417-22-16102 | PARKING BRAKE ASS'Y | 10927-19999 | ||
\0\417-22-16101 | PARKING BRAKE ASS'Y | 10001-10926 | ||
1 | 417-22-16150 | LEVER | 10927- | |
1 | \0\419-22-16140 | LEVER | 10001-10926 | |
2 | 419-22-16110 | KNOB | 10001- | |
3 | 419-22-16120 | SPRING | 10001- | |
4 | 419-22-16130 | WASHER | 10001- | |
5 | 419-22-16150 | PAWL | 10001- | |
6 | 04205-11032 | PIN | 10927- | |
6 | \0\04205-11035 | PIN | 10001-10926 | |
7 | 01641-21016 | WASHER | 10001-10926 | |
8 | 04050-13020 | PIN,COTTER | 10001- | |
9 | 417-22-16113 | BRACKET | 20001- | |
9 | 417-22-16112 | BRACKET | 10927-19999 | |
9 | \0\417-22-16111 | BRACKET | 10001-10926 | |
10 | 04205-11235 | PIN | 20001- | |
10 | 04205-11238 | PIN | 10001-19999 | |
11 | 01641-21223 | WASHER | 10001- | |
12 | 04050-13022 | PIN,COTTER | 10001- | |
13 | 01010-31230 | BOLT | 10001- | |
14 | 01643-31232 | WASHER | 10001- | |
15 | 417-22-16131 | CABLE | 10001- | |
16 | 04205-11035 | PIN | 10001- | |
17 | 04205-11030 | PIN | 10001- | |
18 | 01641-21016 | WASHER | 10001- | |
19 | 04050-13020 | PIN,COTTER | 10001- | |
20 | 417-22-16140 | PLATE | 10001- | |
21 | 08036-21414 | CLIP | 10001- | |
22 | 01010-31220 | BOLT | 10001- | |
23 | 01643-31232 | WASHER | 10001- | |
24 | 417-22-16120 | BRACKET | 10001- | |
25 | 01010-31230 | BOLT | 10001- | |
26 | 01643-31232 | WASHER | 10001- |
