| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 257-70-13600 | PIVOT | 1001- | |
| 2 | 01010-31025 | BOLT | 1001- | |
| 3 | 01602-01030 | WASHER | 1001- | |
| 4 | 257-70-13700 | BRACKET | 1001- | |
| 5 | 257-70-13320 | ROLLER | 1001- | |
| 6 | 01643-30823 | WASHER | 1001- | |
| 7 | 01602-00825 | WASHER | 1001- | |
| 8 | 01580-00806 | NUT | 1001- | |
| 9 | 257-70-13361 | WIRE | 1201- | |
| 257-70-13360 | WIRE | 1001-1200 | ||
| 10 | 266-70-45320 | HOOK | 1001- | |
| 11 | 266-70-45310 | PIN | 1001- | |
| 12 | 04050-12015 | PIN | 1001- | |
| 13 | 268-30-14110 | SPRING | 1001- | |
| 14 | 257-70-13201 | BRACKET | 1042- | |
| 257-70-13200 | BRACKET | 1001-1041 | ||
| 15 | 01010-31025 | BOLT | 1001- | |
| 16 | 01602-01030 | WASHER | 1001- | |
| 17 | 257-70-13400 | BRACKET | 1001- | |
| 18 | 01010-31020 | BOLT | 1001- | |
| 19 | 01602-01030 | WASHER | 1001- | |
| 20 | 265-30-18460 | PIN | 1001- | |
| 21 | 04050-03018 | PIN | 1001- | |
| 22 | 257-70-13330 | WIRE | 1001- | |
| 23 | 266-70-22710 | PIN | 1001- | |
| 24 | 04050-12015 | PIN | 1001- |
