| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 02766-00308 | HOSE | ||
| 2 | 02767-00316 | HOSE | ||
| 3 | 02767-00306 | HOSE | ||
| 4 | 01010-62255 | CAPSCREW - M22 | ||
| 5 | 281-46-11560 | WASHER | ||
| 6 | EF3446 | DISC | ||
| 7 | 561-34-61432 | PLATE | ||
| 8 | EL7427 | PARKING BRAKE ASSEMBLY (SEE INDEX) | ||
| 9 | 04434-52711 | CLIP | ||
| 10 | 07095-20418 | CUSHION | ||
| 11 | 01010-62475 | CAPSCREW - M24 | ||
| 12 | 195-797-5190 | COLLAR | ||
| 13 | 01643-31232 | FLAT WASHER - M12 | ||
| 14 | 01010-81070 | CAPSCREW - M10 X 1.50 X 70 | ||
| 15 | 562-61-32220 | BRACKET | ||
| 16 | 562-61-32210 | BLOCK, JUNCTION | ||
| 17 | 01010-81255 | CAPSCREW - M12 | ||
| 18 | 561-34-61450 | BRACKET | ||
| 19 | 561-34-61460 | SPRING | ||
| 20 | 561-34-61440 | SPRING | ||
| 21 | 01010-62455 | CAPSCREW - M24 | ||
| 22 | 01643-32460 | FLAT WASHER - M24 | ||
| 23 | 04020-01024 | PIN | ||
| 24 | 01643-31032 | FLAT WASHER - M10 | ||
| 25 | 01010-81025 | CAPSCREW - M10 X 1.50 X 25 | ||
| 26 | 02781-00310 | UNION | ||
| 27 | 07002-21423 | O-RING | ||
| 28 | 02896-21009 | O-RING | ||
| 29 | 02782-10422 | ELBOW | ||
| 30 | 07002-22034 | O-RING | ||
| 31 | 02896-21012 | O-RING | ||
| 32 | 01597-01009 | NUT | ||
| 33 | 07283-36365 | CLIP | ||
| 34 | 562-61-32230 | BRACKET | ||
| 35 | 04434-52110 | CLIP | ||
| 36 | 07095-20314 | CUSHION, HOSE | ||
| 37 | 01010-81020 | CAPSCREW - M10 X 1.50 X 20 | ||
| 38 | 562-43-31110 | PLATE |
