| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 566-86-6B211 | WIRING HARNESS | 1055-1999 | |
| 2 | 01010-81020 | BOLT | 1055-1999 | |
| 3 | 01643-31032 | WASHER | 1055-1999 | |
| 4 | 08036-01414 | CLIP | 1055-1999 | |
| 5 | 01010-81016 | BOLT | 1055-1999 | |
| 6 | 01643-31032 | WASHER | 1055-1999 | |
| 7 | 08053-01512 | CLIP | 1055-1999 | |
| 8 | 7861-92-1620 | SENSOR | 1055-1999 | |
| 9 | 07000-51009 | O-RING | 1055-1999 | |
| 561-86-67700 | VALVE ASS'Y | 1055-1999 | ||
| 10 | 561-86-67710 | VALVE | 1055-1999 | |
| 11 | 281-501-1721 | VALVE,CORE | 1055-1999 | |
| 12 | 561-50-63191 | GROMMET | 1055-1999 | |
| 13 | 08034-00576 | BAND | 1055-1999 | |
| 14 | 08036-01014 | CLIP | 1055-1999 |
