| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 8261-62-1150 | TUBE | 1001- | |
| 2 | 207-62-61470 | TUBE | 1001- | |
| 3 | 07000-13035 | O-RING | 1001- | |
| 4 | 07372-21040 | BOLT | 1001- | |
| 5 | 01643-51032 | WASHER | 1001- | |
| 6 | 207-62-61451 | TUBE | 1001- | |
| 7 | 207-62-61531 | BRACKET | 1001- | |
| 8 | 07283-33442 | CLIP | 1001- | |
| 9 | 01599-01011 | NUT | 1001- | |
| 10 | 01643-31032 | WASHER | 1001- | |
| 11 | 07000-13035 | O-RING | 1001- | |
| 12 | 07372-21035 | BOLT | 1001- | |
| 13 | 01643-51032 | WASHER | 1001- | |
| 14 | 07098-01007 | HOSE | 1001- | |
| 15 | 07000-13032 | O-RING | 1001- | |
| 16 | 07371-31049 | FLANGE | 1001- | |
| 17 | 07372-21035 | BOLT | 1001- | |
| 18 | 01643-51032 | WASHER | 1001- | |
| 19 | 07371-31049 | FLANGE | 1001- | |
| 20 | 07372-21035 | BOLT | 1001- | |
| 21 | 01643-51032 | WASHER | 1001- | |
| 22 | 07000-13032 | O-RING | 1001- | |
| 23 | 8229-06-1010 | SWITCH | 1001- | |
| 24 | 07371-31049 | FLANGE | 1001- | |
| 25 | 07378-11000 | HEAD | 1001- | |
| 26 | 07000-13032 | O-RING | 1001- | |
| 27 | 07372-21035 | BOLT | 1001- | |
| 28 | 01643-51032 | WASHER | 1001- |
