| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07103-50305 | HOSE | 10001- | |
| 1A | 20Y-62-22790 | BAND, RED | 10026- | |
| 1A | 20Y-62-22830 | BAND, WHITE | 10026- | |
| 1B | 20Y-62-22810 | BAND, YELLOW | 10026- | |
| 1B | 20Y-62-22830 | BAND, WHITE | 10026- | |
| 1C | 20Y-62-22850 | BAND, GREEN | 10026- | |
| 1D | 20Y-62-22820 | BAND, BLUE | 10026- | |
| 2 | 07230-10315 | UNION | 10015- | |
| 3 | 209-62-57650 | UNION | 10001- | |
| 4 | 07002-12034 | O-RING | 10001- | |
| 5 | 07103-50305 | HOSE | 10001- | |
| 5A | 20Y-62-22860 | BAND, BROWN | 10026- | |
| 6 | 209-62-57641 | ELBOW | 10001- | |
| 7 | 07002-13034 | O-RING | 10001- | |
| 8 | 07103-50306 | HOSE | 10012- | |
| 8A | 20Y-62-22820 | BAND, BLUE | 10026- | |
| 8A | 20Y-62-22790 | BAND, RED | 10026- | |
| 9 | 209-62-57640 | ELBOW | 10001- | |
| 10 | 07002-12034 | O-RING | 10001- | |
| 11 | 19M-61-23890 | BRACKET | 10012- | |
| 12 | 01010-81225 | BOLT | 10012- | |
| 13 | 01643-31232 | WASHER | 10012- | |
| 14 | 19M-61-23881 | NIPPLE | 10012- | |
| 15 | 01010-81230 | BOLT | 10012- | |
| 16 | 01643-51232 | WASHER | 10012- | |
| 17 | 21T-38-12270 | CLIP | 10012- | |
| 17A | 01010-81225 | BOLT | 10012- | |
| 18 | 01643-31232 | WASHER | 10012- | |
| 19 | 19M-61-15160 | BLOCK | 10001- | |
| 20 | 562-15-15950 | STRAINER | 10001- | |
| 21 | 07336-51027 | FLANGE | 10001- | |
| 22 | 07000-13035 | O-RING | 10001- | |
| 23 | 01010-81030 | BOLT | 10001- | |
| 24 | 01602-21030 | WASHER,SPRING | 10012- | |
| 25 | 01010-81230 | BOLT | 10001- | |
| 26 | 01643-31232 | WASHER | 10001- | |
| 27 | 07221-20210 | NUT | 10012- | |
| 28 | 07222-00210 | PLUG | 10012- | |
| 29 | 07103-50306 | HOSE | 10012- | |
| 29A | 20Y-62-22810 | BAND, YELLOW | 10026- | |
| 29B | 20Y-62-22840 | BAND, BLACK | 10026- | |
| 30 | 21T-38-12270 | CLIP | 10012- | |
| 31 | 07103-50306 | HOSE | 10012- | |
| 31A | 20Y-62-22790 | BAND, RED | 10026- | |
| 31B | 20Y-62-22850 | BAND, GREEN | 10026- | |
| 31B | 20Y-62-22830 | BAND, WHITE | 10026- | |
| 32 | 07235-10522 | ELBOW | 10003- | |
| 33 | 07002-12434 | O-RING | 10012- | |
| 34 | 07103-50507 | HOSE | 10012- | |
| 35 | 113-63-22390 | ELBOW | 10012- | |
| 36 | 07235-10522 | ELBOW | 10012- | |
| 37 | 20Y-60-22122 | SOLENOID VALVE | 10012- | |
| 38 | 203-62-32561 | NIPPLE | 10003- | |
| 39 | 07002-12434 | O-RING | 10003- | |
| 40 | 19M-06-21160 | VALVE ASS'Y | 10026- | |
| 41 | 07000-11009 | O-RING | 10001- | |
| 42 | 01220-40545 | SCREW | 10001- | |
| 43 | 08053-01512 | CLIP | 10012- | |
| 44 | 01010-81225 | BOLT | 10012- | |
| 45 | 01643-51232 | WASHER | 10012- | |
| 46 | 01601-20513 | WASHER,SPRING | 10001- | |
| 47 | 21T-38-12270 | CLIP | 10012- | |
| 48 | 01010-81225 | BOLT | 10012- | |
| 49 | 01643-31232 | WASHER | 10012- | |
| 50 | 07235-10315 | ELBOW | 10012- | |
| 51 | 07002-12034 | O-RING | 10012- | |
| 52 | 07042-70108 | PLUG | 10012- | |
| 53 | 07094-00417 | CLAMP | 10012- | |
| 54 | 07095-00423 | CUSHION | 10012- | |
| 55 | 01010-81265 | BOLT | 10012- | |
| 56 | 01643-31232 | WASHER | 10012- |
