| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 17A-49-21120 | COVER | 65275- | |
| 2 | 17A-01-21170 | BRACKET | 65275- | |
| 3 | 01010-81235 | BOLT | 65275- | |
| 4 | 01643-31232 | WASHER | 65275- | |
| 5 | 04434-52512 | CLIP | 65275- | |
| 6 | 01010-81020 | BOLT | 65275- | |
| 7 | 01643-31032 | WASHER | 65275- |
- Главная
- Каталог запчастей
- Бульдозеры
- D155a 5 s/n 65001 up (extreme cold terrain spec.)
- Hydraulic system
- P.p.c. valve piping (cold weather (b) spec.)(#65275 )
Поиск по каталогу
P.P.C. VALVE PIPING (COLD WEATHER (B) SPEC.)(#65275-)
