| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 02762-00341 | HOSE | 10043- | |
| 2 | 02763-003A4 | HOSE | 10043- | |
| 3 | 02782-10315 | ELBOW | 10043- | |
| 4 | 07002-22034 | O-RING | 10001- | |
| 5 | 02896-21009 | O-RING | 10043- | |
| 6 | 19M-61-35140 | TEE | 10043- | |
| 7 | 07002-22034 | O-RING | 10001- | |
| 8 | 02896-21009 | O-RING | 10043- | |
| 9 | 02762-00340 | HOSE | 10043- | |
| 10 | 02762-00333 | HOSE | 10043- | |
| 11 | 02763-003A5 | HOSE | 10043- | |
| 12 | 19M-61-25170 | BRACKET | 10043- | |
| 13 | 01010-81230 | BOLT | 10001- | |
| 14 | 01643-31232 | WASHER | 10001- | |
| 15 | 20Y-62-17930 | CLIP | 10043- | |
| 16 | 01010-81220 | BOLT | 10001- | |
| 17 | 01643-31232 | WASHER | 10001- | |
| 18 | 20Y-03-11220 | COLLAR | 10043- | |
| 19 | 20Y-62-17930 | CLIP | 10043- | |
| 20 | 01010-81295 | BOLT | 10043- | |
| 21 | 01643-31232 | WASHER | 10043- | |
| 22 | 20Y-62-17930 | CLIP | 10043- | |
| 23 | 01010-81220 | BOLT | 10043- | |
| 24 | 01643-31232 | WASHER | 10043- | |
| 25 | 19M-61-37140 | BRACKET | 10043- | |
| 26 | 01010-81225 | BOLT | 10043- | |
| 27 | 01643-31232 | WASHER | 10043- | |
| 28 | 04434-53412 | CLIP | 10043- | |
| 29 | 01010-81220 | BOLT | 10043- | |
| 30 | 01643-31232 | WASHER | 10043- | |
| 31 | 20Y-62-22790 | BAND, RED | 10043- | |
| 32 | 20Y-62-22810 | BAND, YELLOW | 10043- | |
| 33 | 20Y-62-22820 | BAND, BLUE | 10043- | |
| 34 | 20Y-62-22840 | BAND, BLACK | 10043- | |
| 35 | 20Y-62-22850 | BAND, GREEN | 10043- |
