| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | PC0522 | OVERCENTER MANIFOLD VALVE ASSEMBLY (SEE INDEX) | ||
| 2 | TF3231 | CLAMP, SPLIT | ||
| 3 | WA0187 | O-RING | ||
| 4 | C1614 | CAPSCREW - 1/2" - 13NC X 1 1/2" | ||
| 5 | C1540 | LOCKWASHER - 1/2" | ||
| 6 | PB8318 | ELBOW | ||
| 7 | PB6770 | COUPLING, QUICK DISCONNECT (MALE) | ||
| 8 | TY9636 | TUBE | ||
| 9 | EH3596 | TUBE | ||
| 10 | TY8372 | TUBE | ||
| 11 | HA6251 | HOSE | ||
| 12 | VL9963 | CLAMP, SPLIT | ||
| 13 | C1629 | CAPSCREW - 5/8" - 11NC X 1 3/4" | ||
| 14 | C1541 | LOCKWASHER - 5/8" | ||
| 15 | H9918 | CAPSCREW - 3/8" - 16NC X 4 1/2" | ||
| 16 | WA0720 | FLAT WASHER - 3/8" (HARDENED) | ||
| 17 | C0312 | LOCKWASHER - 3/8" | ||
| 18 | C1521 | NUT - 3/8" - 16NC | ||
| 19 | VH6718 | CLAMP, SPLIT | ||
| 20 | WA0232 | O-RING | ||
| 21 | C1615 | CAPSCREW - 1/2" - 13NC X 1 3/4" | ||
| 22 | HA7623 | HOSE | ||
| 23 | TY9635 | TUBE | ||
| 24 | HA6432 | HOSE | ||
| 25 | WA4712 | CLAMP | ||
| 26 | WB0508 | FITTING, ELBOW - 90 DEG | ||
| 27 | EB6439 | BRACKET | ||
| 28 | DC7524 | CAPSCREW - 3/8" - 16NC X 7/8" | ||
| 29 | EJ2461 | MOUNT, PUMP/VALVE | ||
| 30 | VG7000 | MOUNT, CENTER BONDED | ||
| 31 | C1637 | CAPSCREW - 5/8" - 11NC X 3 3/4" | ||
| 32 | WA0361 | FLAT WASHER - 5/8" (HARDENED) | ||
| 33 | TD5915 | WASHER (SPECIAL) | ||
| 34 | C1541 | LOCKWASHER - 5/8" | ||
| 35 | C1525 | NUT - 5/8" - 11NC | ||
| 36 | EH1250 | TUBE | ||
| 37 | WA4709 | CLAMP | ||
| 38 | C1663 | CAPSCREW - 7/8" - 9NC X 3" | ||
| 39 | WA0363 | FLAT WASHER - 7/8" (HARDENED) | ||
| 40 | C1543 | LOCKWASHER - 7/8" | ||
| 41 | C1529 | NUT - 7/8" - 9NC | ||
| 42 | PB7940 | FLANGE, COMPANION | ||
| 43 | EB3976 | WASHER (SPECIAL) | ||
| 44 | H0989 | NUT, JAM - 1" - 14NF | ||
| 45 | C1648 | CAPSCREW - 3/4" - 10NC X 3" | ||
| 46 | WA0362 | FLAT WASHER - 3/4" (HARDENED) | ||
| 47 | TH3747 | LOCKNUT - 3/4" - 10NC | ||
| 48 | ED6147 | ANGLE | ||
| 49 | WA5686 | CLAMP | ||
| 50 | EH1554 | ANGLE | ||
| 51 | WA0360 | FLAT WASHER - 1/2" (HARDENED) | ||
| 52 | C1523 | NUT - 1/2" - 13NC | ||
| 53 | EB6440 | TUBE |
