| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 42W-09-H0660 | HOSE ASSEMBLY | ||
| 2 | 04434-52210 | CLIP | ||
| 3 | 01435-01016 | SCREW | ||
| 4 | 42W-09-H0890 | HOSE ASSEMBLY | ||
| 5 | 42U-09-H1650 | CLAM | ||
| 6 | 42U-09-H1660 | PLATE | ||
| 7 | 01010-80640 | SCREW | ||
| 8 | 42U-70-12860 | BALL VALVE | ||
| 9 | 42U-70-12231 | TUBE | ||
| 10 | 423-00-H0080 | BOXNUT | ||
| 11 | 42U-09-H0940 | OLIVE | ||
| 12 | 42U-70-11G70 | CLIP | ||
| 13 | 01435-00825 | SCREW | ||
| 14 | 42U-09-H1680 | UNION | ||
| 15 | 42U-70-12330 | TERMINAL BLOCK | ||
| 16 | 42U-09-H1440 | SCREW | ||
| 17 | 01010-80860 | SCREW | ||
| 18 | 421-00-H0770 | NUT | ||
| 19 | 42U-70-12H70 | BRACKET | ||
| 20 | 421-00-H0770 | NUT | ||
| 21 | 424-00-H0420 | ELBOW | ||
| 22 | 42W-09-H0880 | HOSE ASSEMBLY | ||
| 23 | 04434-52210 | CLIP | ||
| 24 | 01435-01016 | SCREW | ||
| 25 | 42U-09-H1430 | UNION | ||
| 26 | 42U-70-12J10 | TERMINAL BLOCK | ||
| 27 | 01252-70870 | SCREW | ||
| 28 | 42U-09-H0830 | UNION | ||
| 29 | 42U-09-H1610 | HOSE ASSEMBLY | ||
| 30 | 421-00-H0480 | UNION | ||
| 31 | 42U-09-H0830 | UNION | ||
| 32 | 42U-09-H1610 | HOSE ASSEMBLY | ||
| 33 | 42U-09-H1430 | UNION | ||
| 34 | 01252-70870 | SCREW | ||
| 35 | 42U-70-11D20 | TERMINAL BLOCK | ||
| 36 | 42U-09-H1440 | SCREW | ||
| 37 | 42U-09-H0830 | UNION | ||
| 38 | 42U-00-H0040 | HOSE ASSEMBLY | ||
| 39 | 42U-70-11170 | CHANGE DEVICE | ||
| CHANGE DEVICE | ||||
| 40 | 42U-70-11210 | CHANGE DEVICE | ||
| CHANGE DEVICE | ||||
| 41 | 42U-09-H1690 | SEAL | ||
| 42 | 42U-09-H1430 | UNION | ||
| 43 | 42U-70-12F20 | DUST CAP | ||
| 44 | 42U-70-12E90 | STUD | ||
| 44A | 423-00-H0080 | BOXNUT | ||
| 44B | 42U-09-H0940 | OLIVE | ||
| 45 | 42U-70-12E80 | CONNECTION SOCKET | ||
| 46 | 42U-70-12E70 | THIMBLE | ||
| 47 | 42U-70-H0P28 | O-RING | ||
| 48 | 42U-70-12F10 | DUST CAP | ||
| 49 | 42Y-00-H0810 | STUD | ||
| 50 | 42W-09-H0890 | HOSE ASSEMBLY | ||
| 51 | 42U-09-H0720 | UNION | ||
| 52 | 42U-00-H0580 | HOSE ASSEMBLY | ||
| 53 | 42U-09-H1040 | ELBOW NIPPLE | ||
| 54 | 42U-09-H1050 | NUT | ||
| 55 | 42U-09-H2050 | HOSE PROTECTOR | ||
| 56 | 42U-70-12J70 | SPRING | ||
| 57 | 42U-09-H1690 | SEAL |
