| Item | Part No. | Part Name | Qty | Serial No. |
| 23B-03-61200 | RADIATOR ASS'Y | 51301- | ||
| 1 | 23B-03-61491 | PLATE | 51301- | |
| 2 | 01010-81020 | BOLT | 51301- | |
| 3 | 01643-31032 | WASHER | 51301- | |
| 4 | 23B-03-61531 | SEAL | 51301- | |
| 5 | 23B-03-61541 | SEAL | 51301- | |
| 6 | 23B-03-61551 | SEAL | 51301- | |
| 7 | 01010-81020 | BOLT | 51301- | |
| 8 | 01643-31032 | WASHER | 51301- | |
| 9 | 23B-03-61561 | SEAL | 51301- | |
| 10 | 23B-03-61571 | SEAL | 51301- | |
| 11 | 23B-03-61581 | SEAL | 51301- | |
| 12 | 23B-03-61591 | SEAL | 51301- | |
| 13 | 23B-03-31170 | CAP | 51301- | |
| 14 | 09415-02512 | CAP | 51301- |
