| Item | Part No. | Part Name | Qty | Serial No. |
| 232-03-00164 | RADIATOR ASS'Y | 5641- | ||
| 232-03-00163 | RADIATOR ASS'Y | 5305-5640 | ||
| 232-03-00162 | RADIATOR ASS'Y | 4603-5304 | ||
| 232-03-00161 | RADIATOR ASS'Y | 4029-4602 | ||
| 232-03-00160 | RADIATOR ASS'Y | 3765-4028 | ||
| 232-03-00159 | RADIATOR ASS'Y | 3705-3764 | ||
| 232-03-00158 | RADIATOR ASS'Y | 3573-3704 | ||
| 232-03-00157 | RADIATOR ASS'Y | 3549-3572 | ||
| 232-03-00156 | RADIATOR ASS'Y | 3338-3548 | ||
| 232-03-00155 | RADIATOR ASS'Y | 3071-3337 | ||
| 232-03-00154 | RADIATOR ASS'Y | 2975-3070 | ||
| 232-03-00153 | RADIATOR ASS'Y | 2687-2974 | ||
| 232-03-00152 | RADIATOR ASS'Y | 2591-2686 | ||
| 232-03-00151 | RADIATOR ASS'Y | 2101-2590 | ||
| 232-801-0203 | RADIATOR | 5641- | ||
| 232-801-0202 | RADIATOR | 5305-5640 | ||
| 232-801-0201 | RADIATOR | 4603-5304 | ||
| 232-801-0200 | RADIATOR | 3071-4602 | ||
| 6679-61-7100 | RADIATOR | 2101-3070 | ||
| 1 | 230-03-11470 | STRAINER | 5641- | |
| 1 | 232-801-3570 | STRAINER | 3071-5640 | |
| 2 | 232-03-51130 | SEAT (KIT) | 5641- | |
| 2 | 232-801-3580 | SEAT (KIT) | 3071-5640 | |
| 3 | 232-03-11210 | CLIP | 5641- | |
| 3 | 232-801-3590 | CLIP | 3071-5640 | |
| 4 | 232-03-11192 | PIPE | 5641- | |
| 4 | 232-801-3610 | PIPE | 3071-5640 | |
| 5 | 232-801-3620 | HOSE | 3071- | |
| 6 | 232-801-3511 | RADIATOR | 5641- | |
| 6 | 232-801-3510 | RADIATOR | 3071-5640 | |
| 7 | 232-801-3521 | FRAME | 5641- | |
| 7 | 232-801-3520 | FRAME | 3071-5640 | |
| 8 | 232-801-3532 | SHROUD | 5641- | |
| 8 | 232-801-3531 | SHROUD | 4603-5640 | |
| 8 | 232-801-3530 | SHROUD | 3071-4602 | |
| 9 | 232-801-3540 | SHROUD | 3071-4602 | |
| 10 | 232-801-3552 | NET | 5305- | |
| 10 | \3\232-801-3551 | NET | 4603-5304 | |
| (232-801-3552,232-801-3562) | ||||
| 10 | 232-801-3550 | NET | 3071-4602 | |
| 11 | 232-801-3562 | NET | 5305- | |
| 11 | \3\232-801-3561 | NET | 4603-5304 | |
| (232-801-3562,232-801-3552) | ||||
| 11 | 232-801-3560 | NET | 3071-4602 | |
| 12 | 01010-51014 | BOLT | 3071- | |
| 13 | 01602-21030 | WASHER | 3071- | |
| 14 | 01010-51016 | BOLT | 3071- | |
| 15 | 01602-21030 | WASHER | 3071- | |
| 16 | 232-03-11300 | VALVE ASS'Y | 3071-5640 | |
| 17 | 01010-51030 | BOLT | 3071-5640 | |
| 18 | 01602-21030 | WASHER | 3071-5640 | |
| 19 | 232-03-11170 | GASKET (KIT) | 3071-5640 | |
| 20 | 232-03-11141 | SUPPORT | 3071- | |
| 21 | 232-03-11151 | PAD (KIT) | 3071- | |
| 22 | 01010-50822 | BOLT | 5641- | |
| 22 | 01010-50814 | BOLT | 3071-5640 | |
| 23 | 01602-20825 | WASHER | 3071- | |
| 24 | 232-03-11161 | SHIM | 3071- | |
| 25 | 232-03-11260 | RING | 3071-5640 | |
| 26 | 232-03-11240 | GASKET (KIT) | 3071-5640 | |
| 27 | 101-03-13141 | CAP | 5641- | |
| 27 | 232-03-11220 | CAP | 3071-5640 | |
| 28 | 232-03-11230 | CHAIN | 3071-5640 | |
| 29 | 232-03-11270 | WIRE | 3071-5640 | |
| 31 | 232-03-11442 | SUPPORT | 3705- | |
| 31 | 232-03-11441 | SUPPORT | 2111-3704 | |
| 31 | 232-03-11440 | SUPPORT | 2101-2110 | |
| 32 | 01010-51020 | BOLT | 2975- | |
| 32 | 01000-31020 | BOLT | 2101-2974 | |
| 33 | 01602-21030 | WASHER | 2101- | |
| 34 | 01010-51025 | BOLT | 2975- | |
| 34 | 01000-31020 | BOLT | 2101-2974 | |
| 35 | 01602-21030 | WASHER | 2101- | |
| 35A | 01640-21016 | WASHER | 3705- | |
| 36 | 01580-11008 | NUT | 2975- | |
| 36 | 01500-31008 | NUT | 2101-2974 | |
| 37 | 01010-51635 | BOLT | 2975- | |
| 37 | 01000-31635 | BOLT | 2101-2974 | |
| 38 | 01640-21626 | WASHER | 2101- | |
| 39 | 01602-21648 | WASHER | 2101- | |
| 40 | 232-03-12130 | GASKET (KIT) | 4603- | |
| 40 | 6679-61-6350 | GASKET (KIT) | 2101-4602 | |
| 41 | 01010-51235 | BOLT | 2975- | |
| 41 | 01000-31225 | BOLT | 2101-2974 | |
| 42 | 01602-21236 | WASHER | 2101- | |
| 43 | 232-808-8131 | BEND | 4603- | |
| 43 | 232-808-8130 | BEND | 2687-4602 | |
| 43 | 6679-61-6410 | BEND | 2101-2686 | |
| 44 | 07730-00004 | VALVE | 3549- | |
| 44 | 130-09-19110 | VALVE | 2975-3548 | |
| 44 | 140-999-1560 | VALVE | 2687-2974 | |
| 44 | 6675-61-6800 | VALVE | 2101-2686 | |
| 45 | 07260-01410 | HOSE | 2687-3548 | |
| 45 | 07260-00910 | HOSE | 2101-2686 | |
| 46 | 07280-02523 | CLAMP | 2687-3548 | |
| 46 | 07280-02023 | CLAMP | 2101-2686 | |
| 47 | 232-801-3311 | BEND | 3705-4602 | |
| 47 | 232-801-3310 | BEND | 2687-3704 | |
| 47 | 6679-61-6311 | BEND | 2101-2686 | |
| 47 | 232-808-8210 | BEND,(A) | 3338- | |
| 48 | 232-801-1690 | HOSE | 2101-4602 | |
| 49 | 07281-00809 | CLAMP | 3765-4602 | |
| 49 | 07280-07229 | CLAMP | 2101-3764 | |
| 50 | 232-808-8110 | TUBE | 2687-4602 | |
| 50 | 6679-61-6110 | TUBE | 2101-2686 | |
| 50 | 232-808-8310 | TUBE,(A) | 3338- | |
| 51 | 232-801-1711 | HOSE | 4603- | |
| 51 | 232-801-1710 | HOSE | 2101-4602 | |
| 52 | 232-801-1680 | HOSE | 2101- | |
| 53 | 07281-00809 | CLAMP | 3765- | |
| 53 | 07280-07229 | CLAMP | 2101-3764 | |
| 54 | 232-03-11481 | PLATE | 2975- | |
| 54 | 232-03-11480 | PLATE | 2101-2974 | |
| 55 | 01010-51014 | BOLT | 4029- | |
| 55 | 01010-51014 | BOLT | 3573-4028 | |
| 55 | 01010-51014 | BOLT | 3338-3572 | |
| 55 | 01010-51014 | BOLT | 2975-3337 | |
| 55 | \0\01000-31012 | BOLT | 2101-2974 | |
| 56 | 01602-21030 | WASHER | 4029- | |
| 56 | 01602-21030 | WASHER | 3573-4028 | |
| 56 | 01602-21030 | WASHER | 3338-3572 | |
| 56 | 01602-21030 | WASHER | 2101-3337 | |
| 57 | 07042-20415 | PLUG | 4603- | |
| 57 | 232-03-12160 | CAP | 2591-4602 | |
| 58 | \0\04059-01032 | WIRE | 2591-4602 | |
| 59 | 07281-00809 | CLAMP | 3765- | |
| 59 | 07280-07229 | CLAMP | 2101-3764 | |
| 60 | 232-803-2120 | SHUTTER,(A) | 3601- | |
| 61 | 01235-40412 | SCREW,(A) | 3601- | |
| 62 | 01601-20410 | WASHER,(A) | 3601- |
