| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 177-54-14390 | GUARD | 12128- | |
| 2 | 177-54-13541 | GRILL | 12128- | |
| 3 | 01010-51640 | BOLT | 12128- | |
| 4 | 01643-31645 | WASHER | 23891- | |
| 4 | 01602-21648 | WASHER | 12128-23890 | |
| 5 | 01010-51640 | BOLT | 12128- | |
| 6 | 01643-31645 | WASHER | 23891- | |
| 6 | 01602-21648 | WASHER | 12128-23890 | |
| 7 | 01010-51635 | BOLT | 23891- | |
| 7 | 01010-31640 | BOLT | 12128-23890 | |
| 8 | 01602-21648 | WASHER | 12128-23890 | |
| 9 | 01643-31645 | WASHER | 12128- | |
| 10 | 177-54-13115 | GUARD | 23891- | |
| 10 | 177-54-13114 | GUARD | 12128-23890 | |
| 10 | 177-54-14460 | SEAT | 12128- | |
| 11 | 177-54-13392 | GASKET | 12128- | |
| 12 | 177-54-13870 | PIN | 12128- | |
| 13 | 177-54-13840 | WASHER | 12128- | |
| 14 | 01011-52420 | BOLT | 12128- | |
| 15 | 01643-32460 | WASHER | 23891- | |
| 15 | 01602-22472 | WASHER | 12128-23890 | |
| 16 | 177-54-13710 | BOSS | 12128- | |
| 17 | 01011-83640 | BOLT | 23891- | |
| 17 | 01010-63695 | BOLT | 12128-23890 | |
| 18 | 01643-33690 | WASHER | 23891- | |
| 18 | 01602-23690 | WASHER | 12128-23890 | |
| 18A | 177-54-11220 | SPACER | 23891- | |
| 19 | 01010-51870 | BOLT | 12128- | |
| 20 | 01643-31845 | WASHER | 23891- | |
| 20 | 01602-21854 | WASHER | 12128-23890 | |
| 21 | 01010-51650 | BOLT | 12128- | |
| 22 | 01010-21645 | BOLT | 12128- | |
| 23 | 177-54-13912 | BOLT | 12128- | |
| 24 | 01643-31645 | WASHER | 23891- | |
| 24 | 01602-01648 | WASHER | 12128-23890 | |
| 25 | 177-54-13310 | WASHER | 12128- | |
| 26 | 175-894-3410 | SEAT | 12128- | |
| 27 | 175-894-3390 | PLATE | 12128- | |
| 28 | 01010-51025 | BOLT | 12128- | |
| 29 | 01602-21030 | WASHER | 12128- | |
| 30 | 177-54-13742 | RUBBER | 23891- | |
| 30 | 177-54-13741 | RUBBER | 12128-23890 | |
| 31 | 177-54-13731 | RUBBER | 12128- | |
| 32 | 177-54-13750 | RUBBER | 12128- | |
| 33 | 175-894-3390 | PLATE | 12128- | |
| 34 | 177-54-13760 | PLATE | 12128- | |
| 35 | 175-894-3380 | PLATE | 12128- | |
| 36 | 01010-51025 | BOLT | 12128- | |
| 37 | 01602-21030 | WASHER | 12128- | |
| 38 | 09482-10000 | VALVE | 12128- | |
| 39 | 09483-00518 | HOSE | 12128- | |
| 40 | 130-902-1211 | CLAMP | 12128- | |
| 41 | 130-902-1350 | CLIP | 12128- | |
| 42 | 177-54-13402 | COVER ASS'Y,L.H. | 12128- | |
| 42 | 177-54-13340 | GASKET | 12128- | |
| 43 | 177-54-13302 | COVER ASS'Y,R.H. | 12128- | |
| 43 | 177-54-13340 | GASKET | 12128- | |
| 44 | 177-54-13501 | COVER ASS'Y | 12128- | |
| 44 | 177-54-13360 | GASKET | 12128- | |
| 45 | 01020-01235 | BOLT | 13395- | |
| 45 | \0\177-54-16170 | BOLT | 12128-13394 | |
| 46 | 01602-21236 | WASHER | 12128- | |
| 177-54-15800 | COVER ASS'Y | 23891- | ||
| 177-54-15800 | COVER ASS'Y | 12128-23890 | ||
| 47 | 177-54-15831 | COVER | 12128- | |
| 47 | 177-54-15850 | SEAT | 12128- | |
| 48 | 177-54-15840 | HANDLE | 12128- | |
| 49 | 07000-02018 | O-RING | 12128- | |
| 50 | 177-06-12310 | HANDLE | 12128- | |
| 51 | 177-06-12330 | LOCK | 12128- | |
| 52 | 04025-00424 | PIN | 12128- | |
| 53 | 177-54-14470 | HANDRAIL | 12128- | |
| 54 | 01010-51230 | BOLT | 12128- | |
| 55 | 01602-21236 | WASHER | 12128- | |
| 56 | 177-54-13481 | COVER | 12128- | |
| 57 | 177-54-14200 | COVER ASS'Y | 12128- | |
| 57 | 177-54-14210 | RUBBER | 12128- | |
| 58 | 01010-51030 | BOLT | 12128- | |
| 59 | 01650-21012 | WASHER | 12128- | |
| 60 | 01010-51245 | BOLT | 12128- | |
| 61 | 01602-21236 | WASHER | 12128- | |
| 62 | 01010-51245 | BOLT | 12128- | |
| 63 | 01580-11210 | NUT | 12128- |
