| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 569-03-88612 | BRACKET | 8002- | |
| 1 | 569-03-88611 | BRACKET | 8001-8001 | |
| 2 | 04434-51310 | CLIP | 8002- | |
| 2 | 569-03-88620 | BRACKET | 8001-8001 | |
| 3 | 01010-81020 | BOLT | 8002- | |
| 4 | 01643-31032 | WASHER | 8002- | |
| 5 | 01435-01016 | BOLT | 8002- | |
| 6 | 569-03-88950 | SEAL | 8002- | |
| 7 | 569-03-88960 | SEAL | 8001- | |
| 8 | 569-03-88640 | SEAL | 8001- | |
| 9 | 569-03-88660 | SEAL | 8001- | |
| 10 | 569-03-88670 | SEAL | 8001- | |
| 11 | 569-03-88681 | BRACKET | 8001- | |
| 12 | 569-03-88691 | SEAL | 8001- | |
| 13 | 01435-01016 | BOLT | 8001- | |
| 14 | 569-86-88630 | BAFFLE | 8001- | |
| 15 | 01435-01020 | BOLT | 8001- | |
| 16 | 569-03-88722 | BAFFLE | 8001- | |
| 17 | 01435-01016 | BOLT | 8001- | |
| 18 | 569-03-88881 | BRACKET | 8001- | |
| 19 | 569-03-88891 | SEAL | 8001- | |
| 20 | 01435-01016 | BOLT | 8001- | |
| 21 | 569-03-88861 | BAFFLE | 8001- | |
| 22 | 01435-01020 | BOLT | 8001- | |
| 23 | 569-03-88831 | BAFFLE | 8001- | |
| 24 | 01435-01020 | BOLT | 8001- | |
| 25 | 569-03-88872 | BRACKET | 8004- | |
| 25 | 569-03-88871 | BRACKET | 8001-8003 | |
| 26 | 569-03-88852 | SEAL | 8004- | |
| 26 | 569-03-88851 | SEAL | 8001-8003 | |
| 27 | 569-03-88841 | SEAL | 8004- | |
| 27 | 569-03-88840 | SEAL | 8001-8003 | |
| 28 | 01435-01016 | BOLT | 8001- | |
| 29 | 569-03-88772 | BAFFLE | 8001- | |
| 30 | 01435-01020 | BOLT | 8001- | |
| 31 | 569-03-88781 | BRACKET | 8001- | |
| 32 | 569-03-88910 | SEAL | 8001- | |
| 33 | 569-03-88810 | SEAL | 8001- | |
| 34 | 569-03-88820 | SEAL | 8001- | |
| 35 | 569-03-88790 | SEAL | 8001- | |
| 36 | 01435-01016 | BOLT | 8001- | |
| 37 | 569-03-88730 | BRACKET | 8001- | |
| 38 | 569-03-88740 | SEAL | 8001- | |
| 39 | 01435-01016 | BOLT | 8001- | |
| 40 | 569-03-88750 | SEAL | 8001- | |
| 41 | 569-03-88760 | SEAL | 8001- |
