| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 418-03-11260 | GUARD | 30245- | |
| 2 | 418-03-11270 | GUARD | 30245- | |
| 3 | 01435-01020 | BOLT | 30001- | |
| 4 | 418-03-11330 | PLATE | 20001- | |
| 5 | 416-03-11250 | CUSHION | 20001- | |
| 6 | 416-03-11270 | SPACER | 20001- | |
| 7 | 416-03-11260 | CUSHION | 20001- | |
| 8 | 01010-31245 | BOLT | 20001- | |
| 9 | 419-43-17920 | WASHER | 20001- | |
| 10 | 416-03-11281 | BOLT | 20001- | |
| 11 | 01643-31232 | WASHER | 20001- | |
| 12 | 01580-01210 | NUT | 20001- | |
| 13 | 418-03-11310 | BRACKET,L.H. | 20001- | |
| 14 | 418-03-11320 | BRACKET,R.H. | 20001- | |
| 15 | 01010-31235 | BOLT | 20001- | |
| 16 | 01643-31232 | WASHER | 20001- | |
| 17 | 418-03-11390 | CUSHION | 20001- | |
| 18 | 415-03-11210 | SPACER | 20001- | |
| 19 | 01010-31265 | BOLT | 20001- | |
| 20 | 416-03-11210 | WASHER | 20001- | |
| 21 | 01580-01210 | NUT | 20001- | |
| 22 | 01643-31232 | WASHER | 20001- | |
| 23 | 416-03-11420 | PLATE | 30245- | |
| 24 | 01435-00812 | BOLT | 30245- |
