| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 56D-84-11810 | CURTAIN | 1626- | |
| 2 | 56D-84-11820 | CURTAIN | 1626- | |
| 3 | 409-03-19130 | SNAP | 1626- | |
| 4 | 01602-20720 | WASHER,SPRING | 1626- |
- Главная
- Каталог запчастей
- Самосвалы
- Hm300 1 s/n 1001 up
- Guard
- Radiator curtain (cold spec.)(#1626 )
Поиск по каталогу
RADIATOR CURTAIN (COLD SPEC.)(#1626-)
