| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 7861-93-4520 | SENSOR | 15025- | |
| 2 | 07002-23634 | O-RING | 15025- | |
| 3 | 6210-51-8320 | CLIP | 15025- | |
| 4 | 04434-50810 | CLIP | 15025- | |
| 5 | 01435-01016 | BOLT | 15025- | |
| 6 | 08193-21012 | CLIP | 15025- |
- Главная
- Каталог запчастей
- Самосвалы
- Hd605 7r s/n 15001 15351 (w/o egr)
- Cooling system
- Radiator (electrical system)(#15025 )
Поиск по каталогу
RADIATOR (ELECTRICAL SYSTEM)(#15025-)
