| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 154-03-12626 | GUARD | 28324- | |
| 2 | 175-03-32710 | PIN | 28324- | |
| 3 | 01010-51230 | BOLT | 28324- | |
| 4 | 01643-31232 | WASHER | 28324- | |
| 154-03-00030 | SPRING ASS'Y | 28324- | ||
| 5 | 154-03-13180 | SPACER | 28324- | |
| 6 | 175-54-27350 | SPRING | 28324- | |
| 7 | 01643-32060 | WASHER | 28324- | |
| 8 | 175-54-28770 | RING | 28324- | |
| 9 | 01010-51255 | BOLT | 28324- | |
| 10 | 154-03-13380 | BUMPER | 30693- | |
| 10 | \0\09311-31237 | BUMPER | 26043-30692 | |
| 11 | 01580-11210 | NUT | 28324- | |
| 12 | 154-03-12644 | NET | 28324- | |
| 13 | 154-03-12634 | NET | 28324- | |
| 14 | 01010-51230 | BOLT | 25001- | |
| 15 | 01643-31232 | WASHER | 25001- | |
| 16 | 01010-51230 | BOLT | 25001- | |
| 17 | 01580-11210 | NUT | 25001- | |
| 18 | 01643-31232 | WASHER | 25001- | |
| 19 | 154-03-12653 | NET | 25001- | |
| 20 | 01010-51230 | BOLT | 25001- | |
| 21 | 01643-31232 | WASHER | 25001- | |
| 22 | 154-03-12871 | STAY | 25001- | |
| 23 | 01010-51230 | BOLT | 25001- | |
| 24 | 175-54-34170 | WASHER | 29501- | |
| 24 | \0\124-54-26540 | WASHER | 25001-29500 | |
| 25 | 170-03-13130 | SPACER | 25001- | |
| 26 | 154-03-12880 | SEAT | 25001- | |
| 27 | 175-54-34170 | WASHER | 29501- | |
| 27 | \0\124-54-26540 | WASHER | 25001-29500 | |
| 28 | 01010-51265 | BOLT | 25001- | |
| 29 | 154-03-12135 | PROTECTOR (OP) | 28324- | |
| 30 | 01010-51020 | BOLT (OP) | 28324- | |
| 31 | 01643-31032 | WASHER (OP) | 25001- | |
| 32 | 198-03-22410 | PLATE (OP) | 28324- | |
| 33 | 01010-51025 | BOLT (OP) | 28324- | |
| 34 | 01643-31032 | WASHER (OP) | 28324- |
