| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 421-62-41480 | Hose | 90216- | |
| 2 | 421-62-41120 | Tube | 90216- | |
| 3 | 421-62-41240 | Hose | 90216- | |
| 4 | 421-62-41130 | Tube | 90216- | |
| 5 | 421-62-41490 | Hose | 90216- | |
| 6 | 421-62-41140 | Tube | 90216- | |
| 7 | 02896-11015 | O-ring | 90216- | |
| 8 | 02896-11012 | O-ring | 90216- | |
| 9 | 01010-81020 | Bolt | 90216- | |
| 10 | 01643-31032 | Washer | 90216- | |
| 11 | 421-62-41150 | Plate | 90216- | |
| 12 | 01010-81020 | Bolt | 90216- | |
| 13 | 01643-31032 | Washer | 90216- | |
| 14 | 421-62-41211 | Bracket | 90216- | |
| 15 | 07283-32236 | Clip, Pipe | 90216- | |
| 16 | 07283-52232 | Seat | 90216- | |
| 17 | 01643-31032 | Washer | 90216- | |
| 18 | 01597-01009 | Nut | 90216- | |
| 19 | 01010-81025 | Bolt | 90216- | |
| 20 | 01643-31032 | Washer | 90216- | |
| 21 | 04434-52110 | Clip | 90216- | |
| 22 | 01010-81020 | Bolt | 90216- | |
| 23 | 01643-31032 | Washer | 90216- | |
| 24 | (421-62-41810) | Bracket | - |
