| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 04010-00519 | Key, Woodruff | C10001- | |
| 2 | 01010-81035 | Bolt | C10001- | |
| 3 | 01643-31032 | Washer | C10001- | |
| 4 | 427-43-28660 | Union | C10001- | |
| 5 | 07002-12034 | O-ring | C10001- | |
| 6 | 02896-11012 | O-ring | C10001- | |
| 7 | 02783-10422 | Elbow | C10001- | |
| 8 | 07002-12034 | O-ring | C10001- | |
| 9 | 02896-11012 | O-ring | C10001- | |
| 10 | 22J-62-25121 | Elbow | C10001- | |
| 11 | 07002-11423 | O-ring | C10001- | |
| 12 | 02896-11009 | O-ring | C10001- | |
| 13 | 418-03-43830 | Tube | C10001- | |
| 14 | 418-03-43840 | Plate | C10001- | |
| 15 | 07283-32244 | Clip | C10001- | |
| 16 | 07283-52232 | Seat | C10001- | |
| 17 | 01643-31032 | Washer | C10001- | |
| 18 | 01597-01009 | Nut | C10001- | |
| 19 | 04434-50610 | Clip | C10001- | |
| 20 | 01010-81020 | Bolt | C10001- | |
| 21 | 01643-31032 | Washer | C10001- | |
| 22 | 01010-81025 | Bolt | C10001- | |
| 23 | 01643-31032 | Washer | C10001- | |
| 24 | 01010-81020 | Bolt | C10001- | |
| 25 | 01643-31032 | Washer | C10001- | |
| 26 | 418-03-43850 | Bracket | C10001- | |
| 27 | 418-03-43860 | Bracket | C10001- | |
| 28 | 01010-81020 | Bolt | C10001- | |
| 29 | 01643-31032 | Washer | C10001- |
