Item | Part No. | Part Name | Qty | Serial No. |
1 | 135-A62-3110 | MASK,RADIATOR | 20001- | |
2 | 01010-51290 | BOLT | 20001- | |
3 | 01010-51285 | BOLT | 20001- | |
4 | 01010-51235 | BOLT | 20001- | |
5 | 01602-21236 | WASHER,SPRING | 20001- | |
6 | 135-A62-3150 | SEAT | 20001- | |
7 | 120-54-31391 | PLATE | 20001- | |
8 | 135-A62-3120 | BRACKET | 20001- | |
9 | 135-A62-3130 | BAFFLE | 20001- | |
10 | 135-A62-3140 | COVER | 20001- | |
11 | 01010-51225 | BOLT | 20001- | |
12 | 01602-21236 | WASHER,SPRING | 20001- | |
13 | 125-54-27360 | COLLAR | 20001- | |
14 | 01010-51060 | BOLT | 20001- | |
15 | 01580-11008 | NUT | 20001- | |
16 | 135-A62-6210 | GUARD,RADIATOR | 20001- | |
17 | 135-54-31181 | CATCHER,L.H. | 20001- | |
18 | 135-54-31191 | CATCHER,R.H. | 20001- | |
19 | 01010-51225 | BOLT | 20001- | |
20 | 01602-21236 | WASHER,SPRING | 20001- | |
21 | 01018-12045 | BOLT | 20001- | |
22 | 01643-32060 | WASHER | 20001- | |
23 | 04089-02014 | NUT | 20001- |
