| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 195-03-22501 | ISOLATOR ASS'Y | 8513- | |
| 1 | \0\195-03-22500 | ISOLATOR ASS'Y | 8502-8512 | |
| 1 | 198-03-22320 | BRACKET | 8497-8501 | |
| 2 | 195-03-22270 | SHIM, 1.0MM | 8497- | |
| 3 | 01010-31245 | BOLT | 8497- | |
| 4 | 01643-31232 | WASHER | 8497- | |
| 5 | 198-03-22330 | BRACKET | 8497-8501 | |
| 6 | 198-03-22450 | WASHER | 8497-8501 | |
| 7 | 01010-31260 | BOLT | 8497-8501 | |
| 8 | 175-03-32972 | BRACKET,L.H. | 8502- | |
| 8 | 175-03-32971 | BRACKET,L.H. | 8497-8501 | |
| 8 | 175-03-32981 | BRACKET,R.H. | 8497-8501 | |
| 9 | 01010-31435 | BOLT | 8497- | |
| 10 | 01643-31445 | WASHER | 8497- | |
| 11 | 175-03-32760 | BRACKET,L.H. | 8497- | |
| 11 | 175-03-32770 | BRACKET,R.H. | 8497- | |
| 12 | 01010-31230 | BOLT | 8502- | |
| 12 | \0\01010-31225 | BOLT | 8497-8501 | |
| 13 | 01643-31232 | WASHER | 8497- | |
| 14 | 198-03-28290 | ISOLATOR | 8497-8501 | |
| 15 | 01091-32220 | BOLT | 8502- | |
| 15 | 01090-32295 | BOLT | 8497-8501 | |
| 16 | 01643-32260 | WASHER | 8502- | |
| 16 | 01643-32260 | WASHER | 8497-8501 | |
| 17 | 175-03-32951 | BRACKET | 8497- | |
| 18 | 175-03-32961 | BRACKET | 8497- | |
| 19 | 01010-31230 | BOLT | 8502- | |
| 19 | \0\01010-31225 | BOLT | 8497-8501 | |
| 20 | 01643-31232 | WASHER | 8497- | |
| 21 | 195-03-22401 | ISOLATOR ASS'Y | 8513- | |
| 21 | \0\195-03-22400 | ISOLATOR ASS'Y | 8502-8512 | |
| 21 | 198-03-22270 | BRACKET | 8497-8501 | |
| 22 | 198-03-21530 | PLATE | 8497- | |
| 23 | 01010-31075 | BOLT | 8497- | |
| 24 | 01643-01032 | WASHER | 8497- | |
| 25 | 01011-31225 | BOLT | 8497-8501 | |
| 26 | 01602-01236 | WASHER,SPRING | 8497-8501 | |
| 27 | 198-03-22290 | ISOLATOR | 8497-8501 | |
| 28 | 01091-32220 | BOLT | 8497- | |
| 29 | 01643-32260 | WASHER | 8497- | |
| 30 | 01582-02218 | NUT | 8502- | |
| 30 | 01582-02218 | NUT | 8497-8501 |
