| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 561-03-31510 | HOSE | 1002- | |
| 2 | 575-97-11190 | SHEET | 1002- | |
| 3 | 04059-01680 | WIRE | 1002- | |
| 4 | 07281-01029 | CLAMP | 1002- | |
| 5 | 561-03-31520 | TUBE | 1002- | |
| 6 | 07371-03010 | FLANGE | 1002- | |
| 7 | 07000-02085 | O-RING | 1002- | |
| 8 | 07372-21650 | BOLT | 1002- | |
| 9 | 01602-21648 | WASHER | 1002- | |
| 10 | 07042-20108 | PLUG | 1002- | |
| 11 | 561-03-31360 | BRACKET | 1002- | |
| 12 | 01010-51220 | BOLT | 1002- | |
| 13 | 01602-21236 | WASHER | 1002- | |
| 14 | 07283-28973 | CLIP | 1002- | |
| 15 | 01599-01214 | NUT | 1002- | |
| 16 | 01643-31232 | WASHER | 1002- | |
| 17 | 561-03-31530 | TUBE | 1002- | |
| 18 | 01010-51235 | BOLT | 1002- | |
| 19 | 01602-21236 | WASHER | 1002- | |
| 20 | 07000-02090 | O-RING | 1002- | |
| 21 | 568-03-22410 | HOSE | 1002- | |
| 22 | 07281-01159 | CLAMP | 1002- | |
| 23 | 561-03-31540 | TUBE | 1002- | |
| 24 | 07000-02085 | O-RING | 1002- | |
| 25 | 01011-51410 | BOLT | 1002- | |
| 26 | 01643-31445 | WASHER | 1002- | |
| 27 | 07042-20108 | PLUG | 1002- | |
| 28 | 561-03-31611 | TUBE | 1002- | |
| 29 | 07000-02120 | O-RING | 1002- | |
| 30 | 01010-51240 | BOLT | 1002- | |
| 31 | 01602-21236 | WASHER | 1002- | |
| 32 | 07281-01159 | CLAMP | 1002- | |
| 33 | 07260-28728 | HOSE | 1002- | |
| 34 | 561-03-31621 | TUBE | 1002- | |
| 35 | 07000-02085 | O-RING | 1002- | |
| 36 | 01010-51240 | BOLT | 1002- | |
| 37 | 01602-21236 | WASHER | 1002- | |
| 38 | 561-03-31371 | BRACKET | 1002- | |
| 39 | 07283-28973 | CLIP | 1002- | |
| 40 | 01599-01214 | NUT | 1002- | |
| 41 | 01643-31232 | WASHER | 1002- | |
| 42 | 01010-51030 | BOLT | 1002- | |
| 43 | 01602-21030 | WASHER | 1002- | |
| 44 | 07042-20108 | PLUG | 1002- |
