| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 209-03-51231 | TUBE | 10084- | |
| 1 | \0\209-03-51230 | TUBE | 10001-10083 | |
| 2 | 6210-61-6441 | GASKET | 10109- | |
| 2 | 6210-61-6440 | GASKET | 10001-10108 | |
| 3 | 01010-81035 | BOLT | 10085- | |
| 3 | 01010-51035 | BOLT | 10001-10084 | |
| 4 | 01643-31032 | WASHER | 10001- | |
| 5 | 209-03-51261 | HOSE | 10020- | |
| 5 | \0\209-03-51260 | HOSE | 10001-10019 | |
| 6 | 07289-00070 | CLAMP | 10080- | |
| 6 | \1\208-09-11120 | CLAMP | 10001-10079 | |
| 7 | 209-03-51241 | TUBE | 10084- | |
| 7 | \0\209-03-51240 | TUBE | 10001-10083 | |
| 8 | 195-03-18651 | GASKET | 10055- | |
| 8 | \0\195-03-18650 | GASKET | 10001-10054 | |
| 9 | 01010-81235 | BOLT | 10085- | |
| 9 | 01010-51235 | BOLT | 10001-10084 | |
| 10 | 01643-31232 | WASHER | 10001- | |
| 11 | 21T-03-71440 | TUBE | 10001- | |
| 12 | 07285-00095 | CLIP | 10001- | |
| 13 | 08036-01414 | CLIP | 10001- | |
| 14 | 01010-81220 | BOLT | 10085- | |
| 14 | 01010-51220 | BOLT | 10001-10084 | |
| 15 | 01643-31232 | WASHER | 10001- | |
| 16 | 08034-00519 | BAND | 10001- | |
| 17 | 07260-20990 | HOSE | 10001- | |
| 18 | 07281-00197 | CLAMP | 10001- | |
| 19 | 07343-24808 | GASKET | 10084- | |
| 19 | 07343-04808 | GASKET | 10001-10083 | |
| 20 | 209-03-51310 | ELBOW | 10001- | |
| 21 | 01010-81260 | BOLT | 10085- | |
| 21 | 01010-51260 | BOLT | 10001-10084 | |
| 22 | 01643-31232 | WASHER | 10001- | |
| 23 | 07343-02708 | GASKET | 10001- | |
| 24 | 209-03-51320 | TUBE | 10001- | |
| 25 | 01010-81030 | BOLT | 10086- | |
| 25 | 01010-81035 | BOLT | 10001-10085 | |
| 26 | 01643-31032 | WASHER | 10001- | |
| 27 | 198-911-5120 | HOSE | 10136- | |
| 27 | 195-03-18680 | HOSE | 10001-10135 | |
| 28 | 07289-00045 | CLAMP | 10080- | |
| 28 | \1\207-09-11110 | CLAMP | 10001-10079 | |
| 29 | 195-03-11511 | CLIP | 10001- | |
| 30 | 01010-81225 | BOLT | 10085- | |
| 30 | 01010-51225 | BOLT | 10001-10084 | |
| 31 | 01643-31232 | WASHER | 10001- | |
| 32 | 08034-00834 | BAND | 10001- |
