| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | (144-03-00017) | RADIATOR ASS'Y | .- | |
| \0\144-03-00016 | RADIATOR ASS'Y | 30001-. | ||
| 2 | 144-03-12133 | TUBE | 20054- | |
| 3 | 144-03-12170 | PACKING | 22388- | |
| 4 | 01010-31235 | BOLT | 20006- | |
| 5 | 01602-01236 | WASHER | 20006- | |
| 6 | 144-03-13142 | TUBE | .- | |
| 7 | 07730-30004 | VALVE | 28013- | |
| 8 | 07270-01530 | TUBE | .- | |
| 9 | 04059-01010 | WIRE | 22388- | |
| 10 | 144-03-12160 | PACKING | 20006- | |
| 11 | 01010-31030 | BOLT | 20006- | |
| 12 | 01602-01030 | WASHER | 20006- | |
| 13 | 144-03-13150 | HOSE | 20024- | |
| 14 | 07281-00809 | CLAMP | 28061- | |
| 15 | 144-03-11251 | HOSE | 28061- | |
| 16 | 07281-00809 | CLAMP | 28061- | |
| 17 | 144-03-11241 | HOSE | 28061- | |
| 18 | 07281-00419 | CLAMP | 30001- | |
| 19 | 6631-11-6231 | ELBOW | 20006- | |
| 20 | 07260-00970 | HOSE | 20006- | |
| 21 | 07280-01920 | CLAMP | 21388- | |
| 22 | 144-03-12211 | BRACKET | 20006- | |
| 23 | 141-03-13380 | CLIP | 20006- | |
| 24 | 01010-31222 | BOLT | 20006- | |
| 25 | 01602-01236 | WASHER | 20006- | |
| 26 | 144-03-11355 | SHROUD | 30001- | |
| 27 | 01010-31230 | BOLT | 20006- | |
| 28 | 01602-01236 | WASHER | 20006- | |
| 29 | 01643-31232 | WASHER | 20006- | |
| 30 | 144-03-11321 | COVER | 20006- | |
| 31 | 01010-31025 | BOLT | 20006- | |
| 32 | 01602-01030 | WASHER | 20006- | |
| 33 | 01642-21016 | WASHER | 20006- | |
| 34 | 144-03-11440 | NET | .- | |
| \3\144-03-11364 | NET | 28061-. | ||
| (144-03-11440{144-03-11430¤} | ||||
| 01010-31020(9){01602-01030(9))} | ||||
| 35 | 144-03-11374 | NET | 28061- | |
| 36 | 01010-31020 | BOLT | .- | |
| 01010-31020 | BOLT | 28061-. | ||
| 37 | 01602-01030 | WASHER | .- | |
| 01602-01030 | WASHER | 28061-. | ||
| 38 | 144-03-11430 | NET | .- |
