| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 23B-03-33611 | HOSE | B15001- | |
| 2 | 07289-00070 | CLAMP | B15001- | |
| 3 | 23B-03-33710 | TUBE | B15001- | |
| 4 | 07282-16114 | CLAMP | B15001- | |
| 5 | 01010-81230 | BOLT | B15001- | |
| 6 | 01643-31232 | WASHER | B15001- | |
| 7 | 23B-03-33621 | HOSE | B15001- | |
| 8 | 07289-00070 | CLAMP | B15001- | |
| 9 | 23B-03-33780 | TUBE | B15001- | |
| 10 | 01435-01016 | BOLT | B15001- | |
| 11 | 23B-03-33630 | HOSE | B15001- | |
| 12 | 07289-00070 | CLAMP | B15001- | |
| 13 | 23B-03-33641 | HOSE | B15001- | |
| 14 | 07289-00070 | CLAMP | B15001- | |
| 15 | 23B-03-34151 | HOSE | B15001- | |
| 16 | 07289-00070 | CLAMP | B15001- | |
| 17 | 23A-03-31751 | HOSE | B15001- | |
| 18 | 07289-00070 | CLAMP | B15001- | |
| 19 | 23B-03-32130 | TUBE | B15001- | |
| 20 | 01010-81025 | BOLT | B15001- | |
| 21 | 01643-31032 | WASHER | B15001- | |
| 22 | 07042-70108 | PLUG | B15001- | |
| 23 | 23B-03-34120 | TUBE | B15001- | |
| 24 | 01010-81020 | BOLT | B15001- | |
| 25 | 01643-31032 | WASHER | B15001- | |
| 26 | 07730-40004 | VALVE | B15001- | |
| 27 | 07260-21416 | HOSE | B15001- | |
| 28 | 07281-00259 | CLAMP | B15001- | |
| 29 | 08034-00536 | BAND | B15001- | |
| 30 | 23B-03-31790 | PLATE | B15001- | |
| 31 | 01010-81020 | BOLT | B15001- | |
| 32 | 01643-31032 | WASHER | B15001- |
