| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 01010-51640 | BOLT | 11001-@ | |
| 2 | 01643-31645 | WASHER | 11001-@ | |
| 3 | 23F-03-12210 | BRACKET,L.H. | 11001-@ | |
| 4 | 23F-03-12220 | BRACKET,R.H. | 11001-@ | |
| 5 | 01010-51022 | BOLT | 11001-@ | |
| 6 | 01643-31032 | WASHER | 11001-@ | |
| 7 | 23F-03-12140 | TUBE | 11001-12000 | |
| 8 | 07043-70415 | PLUG | 11022-@ | |
| 07043-00415 | PLUG | 11001-11021 | ||
| 9 | 232-03-12131 | GASKET | 11001-@ | |
| (\2\232-03-12130) | GASKET | (11001-11021) | ||
| 10 | 01010-51225 | BOLT | 11001-@ | |
| 11 | 01641-21223 | WASHER | 11001-@ | |
| 12 | 23F-03-12120 | HOSE | 11001-@ | |
| 13 | 07289-00070 | CLAMP | 11035-@ | |
| 07281-00809 | CLAMP | 11001-11034 | ||
| 14 | 23B-04-11241 | CONNECTOR | 11001-@ | |
| 15 | 07042-30415 | PLUG | 11003-@ | |
| \0\07042-70415 | PLUG | 11001-11002 | ||
| 16 | 234-991-1421 | GASKET | 11001-@ | |
| (\2\234-991-1420) | GASKET | (11001-11021) | ||
| 17 | 01010-51050 | BOLT | 11001-@ | |
| 18 | 01643-31032 | WASHER | 11003-@ | |
| \0\01641-21016 | WASHER | 11001-11002 | ||
| 19 | 23F-03-12110 | HOSE | 11001-12000 | |
| 20 | 07289-00070 | CLAMP | 11035-@ | |
| 07281-00809 | CLAMP | 11001-11034 | ||
| 21 | 23A-03-11350 | CHOKE | 11001-@ | |
| 22 | 07260-20980 | HOSE | 11001-@ | |
| 23 | 07281-00197 | CLAMP | 11001-@ | |
| 24 | 234-991-1460 | TUBE | 11001-12000 | |
| 25 | 08034-00536 | BAND | 11001-@ | |
| 26 | 07261-22620 | HOSE | 11002-@ | |
| \0\07261-22621 | HOSE | 11001-11001 | ||
| 27 | 07281-00419 | CLAMP | 11001-@ | |
| 28 | 234-03-15210 | NIPPLE | 11001-@ | |
| 29 | 232-807-1551 | CLIP | 11001-@ | |
| 30 | 01010-51020 | BOLT | 11001-@ | |
| 31 | 07730-50004 | VALVE | 11001-@ | |
| 32 | 07270-61210 | TUBE | 11002-@ | |
| \0\07270-61212 | TUBE | 11001-11001 | ||
| 33 | 273-60-24450 | TUBE,SPIRAL | 11006-@ | |
| 34 | 08034-00519 | BAND | 11006-@ |
