| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | XC2583 | AXLE HOUSING ASSEMBLY | | |
| 2 | TX8110 | SLEEVE (2) | | |
| 3 | WB1162 | CAPSCREW - 1 1/4" - 7NC X 3" (12 PT) | | |
| 4 | WA0366 | FLAT WASHER - 1 1/4" (HARDENED) | | |
| 5 | XB2450 | PIVOT EYE ASSEMBLY | | |
| 5 | XB2449 | EYE, PIVOT | | |
| 6 | PC1291 | BEARING (1) | | |
| 7 | WB1154 | CAPSCREW - 3/4" - 10NC X 6" (12 PT) (1) | | |
| 8 | VL2993 | LOCKNUT - 3/4" - 10NC (1) | | |
| 9 | EL0047 | RETAINER, BEARING (1) | | |
| 10 | ED4952 | SLEEVE (1) | | |
| 11 | EK0867 | PIN, PIVOT (1) | | |
| 12 | VN9952 | LOCKNUT - 5/8" - 11NC (2) | | |
| 13 | EG3028 | SPACER (1) | | |
| 14 | EK0866 | PLATE, LOCKING (1) | | |
| 15 | WB1059 | CAPSCREW - 1 1/4" - 7NC X 4 1/2" (12 PT) (1) | | |
| 16 | WA0361 | FLAT WASHER - 5/8" (HARDENED) (2) | | |
| 17 | VN9087 | CAPSCREW - 5/8" - 11NC X 2 1/2" (1) | | |
| 18 | C1541 | LOCKWASHER - 5/8" (1) | | |
| 19 | EM8109 | SHOULDER BOLT - 5/8" - 11NC X 7.16" (FRAME END) (2) | | |
| 19 | EM8110 | SHOULDER BOLT - 5/8" - 11NC X 6.73" (AXLE END) (2) | | |
| 20 | TY2734 | SPACER (2) | | |
| 21 | EH7812 | ANTI-SWAY BAR W/ BEARINGS | | |
| 21 | EH7813 | BAR, ANTI-SWAY | | |
| 22 | VN9351 | RING, RETAINER (2) | | |
| 23 | PB0027 | BEARING, SPHERICAL (2) | | |
| 24 | EH7811 | PIN, BEARING (2) | | |
| 25 | XB2497 | WIRE, GROUND (PIVOT EYE TO FRAME) | | |
| 26 | MM0471 | LOCKWASHER - M10 | | |
| 27 | MM0178 | NUT - M10 X 1.50 | | |
| 28 | MM0603 | CAPSCREW - M10 X 1.50 X 16 | | |
| NS|32 | AK5258 | NOTE: (1) INCLUDED IN AK5258 NOSE CONE PIN KIT. | | |
| NS|33 | AK5672 | (2) INCLUDED IN AK5672 PANHARD PIN KIT. | | |
