| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 423-06-54191 | Lamp | 5001-@ | |
| 1 | 421-06-23330 | Bulb, 70watt | 5001-@ | |
| 2 | 01010-81020 | Bolt | 5001-@ | |
| 3 | 01643-31032 | Washer | 5001-@ | |
| 4 | 22B-06-21930 | Backup Alarm | 5001-@ | |
| 5 | 01010-80816 | Bolt | 5001-5155 | |
| 6 | 01643-30823 | Washer | 5001-@ | |
| 7 | 7861-93-5380 | Sensor, Angle | 5001-@ | |
| 8 | 01010-80635 | Bolt | 5001-@ | |
| 9 | 01643-30623 | Washer | 5001-@ | |
| 10 | 08053-01510 | Clip | 5001-@ | |
| 11 | 08193-21012 | Clip | 5001-5155 | |
| 12 | 01010-81016 | Bolt | 5001-5155 | |
| 13 | 01643-31032 | Washer | 5001-5155 | |
| 14 | 565-03-11270 | Cushion | 5001-@ | |
| 15 | 01010-80816 | Bolt | 5001-5155 | |
| 16 | 01643-30823 | Washer | 5001-@ | |
| 17 | 04434-50510 | Clip | 5001-@ | |
| 18 | 08037-03614 | Grommet | 5001-@ | |
| 19 | 56B-06-33150 | Wiring Harness | 5001-@ | |
| 20 | 04434-51010 | Clip | 5001-@ | |
| 21 | 08193-21012 | Clip | 5001-5155 | |
| 22 | 56D-06-34150 | Lamp Assembly, Tail | 5001-@ | |
| 23 | 56D-06-34160 | Lamp Assembly, Turn Signal | 5001-@ | |
| 24 | 56B-06-3A151 | Bracket | 5001-5155 | |
| 25 | 56B-06-3A130 | Bracket | 5001-5155 | |
| 26 | 01010-80816 | Bolt | 5001-@ | |
| 27 | 01643-30823 | Washer | 5001-@ | |
| 28 | Connector Body Assembly | 5001-@ | ||
| 29 | 08191-00770 | Plug, Connector | 5001-@ | |
| 30 | 14X-98-35181 | Plate, Reflector | 5001-@ | |
| 31 | 01643-31032 | Washer | 5001-@ | |
| 32 | 01580-11008 | Nut | 5001-@ | |
| 33 | 56B-06-35130 | Bracket | 5001-5155 | |
| 34 | 01010-80816 | Bolt | 5001-5155 | |
| 35 | 01643-30823 | Washer | 5001-@ |
