| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 103-54-24412 | FENDER,REAR, L.H. | 45001- | |
| 1 | 103-54-24421 | FENDER,REAR, R.H. | 45001- | |
| 2 | 01010-31435 | BOLT | 45001- | |
| 3 | 01010-31430 | BOLT | 45001- | |
| 4 | 01602-01442 | WASHER,SPRING | 45001- | |
| 5 | 103-54-24315 | CASE,WITH HYDRAULIC TANK | 47923- | |
| 5 | 103-54-24314 | CASE,WITH HYDRAULIC TANK | 45916-47922 | |
| 5 | \3\103-54-24313 | CASE,WITH HYDRAULIC TANK | 45001-45915 | |
| (103-54-24314,103-62-23312) | ||||
| 6 | 113-54-24230 | BOLT | 45001- | |
| 7 | 01580-00605 | NUT | 45001- | |
| 8 | 07044-12412 | PLUG | 45001- | |
| 9 | 07002-02434 | O-RING | 45001- | |
| 10 | 10E-60-12150 | PLATE | 45001- | |
| 11 | 07715-11257 | RING | 45001- | |
| 12 | 07715-00651 | COVER | 45001- | |
| 13 | 10E-60-12160 | COVER | 45001- | |
| 14 | 01010-30820 | BOLT | 45001- | |
| 15 | 01602-00825 | WASHER,SPRING | 45001- | |
| 16 | 10E-03-11130 | CAP | 45001- | |
| 17 | (103-04-00020) | FUEL TANK ASS'Y | 45001- | |
| 18 | 01010-31430 | BOLT | 45001- | |
| 19 | 01602-01442 | WASHER,SPRING | 45001- | |
| 20 | 01643-31445 | WASHER | 45001- | |
| 21 | 103-54-24172 | COVER | 45001- | |
| 22 | 103-54-24332 | COVER | 45001- | |
| 23 | 103-54-24430 | COVER | 45001- | |
| 24 | 01010-31025 | BOLT | 45001- | |
| 25 | 01602-01030 | WASHER,SPRING | 45001- | |
| 26 | 01643-31032 | WASHER | 45001- | |
| 27 | 103-54-24341 | COVER | 45001- | |
| 28 | 113-54-24230 | BOLT | 45001- | |
| 29 | 01580-00605 | NUT | 45001- | |
| 30 | 103-54-24322 | COVER | 45001- | |
| 31 | 103-54-24133 | COVER | 50001- | |
| 31 | \0\103-54-24132 | COVER | 45001-50000 | |
| 31 | 103-54-24213 | COVER,(FOR SUSPENSION SEAT) | 50001- | |
| 31 | \0\103-54-24212 | COVER,(FOR SUSPENSION SEAT) | 45001-50000 | |
| 31A | 08036-01414 | CLIP | 50001- | |
| 31B | 01010-31016 | BOLT | 50001- | |
| 31C | 01602-01030 | WASHER,SPRING | 50001- | |
| 32 | 103-54-24142 | COVER | 45001- | |
| 33 | 01010-31025 | BOLT | 45001- | |
| 34 | 01602-01030 | WASHER,SPRING | 45001- | |
| 35 | 01643-31032 | WASHER | 47923- | |
| 35 | 103-54-24440 | WASHER | 45001-47922 | |
| 36 | 103-Z06-1151 | BRACKET,L.H. | 45001- | |
| 36 | 101-Z54-6130 | BRACKET,R.H. | 52376- | |
| 36 | 103-Z06-1151 | BRACKET,R.H. | 45001-52375 | |
| 37 | 01010-31435 | BOLT | 45001- | |
| 38 | 01602-01442 | WASHER,SPRING | 45001- | |
| 39 | 01016-31445 | BOLT | 45001- | |
| 40 | 01580-01411 | NUT | 45001- |
