| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 08128-22400 | LAMP ASS'Y,REAR | 1002-@ | |
| 1 | 08113-02480 | BULB, 80W | 1002-@ | |
| 2 | 566-06-15750 | FLICKER | 1002-@ | |
| 3 | 08160-22400 | HORN | 1002-@ | |
| 4 | 01010-30612 | BOLT | 1002-@ | |
| 5 | 01602-00619 | WASHER | 1002-@ | |
| 6 | 281-06-13121 | LAMP ASS'Y,BRAKE AND TAIL | 1002-1052 | |
| 6 | 08104-12420 | BULB, 25/10W | 1002-@ | |
| 6 | 08111-12420 | BULB | 1002-1052 | |
| 7 | 281-06-13140 | LAMP ASS'Y,TURN SIGNAL | 1002-1052 | |
| 7 | 08105-12420 | BULB, 25W | 1002-@ | |
| 8 | 567-06-13360 | BRACKET | 1002-@ | |
| 9 | 01580-01008 | NUT | 1002-@ | |
| 10 | 01602-01030 | WASHER | 1002-@ | |
| 11 | 01643-21032 | WASHER | 1002-@ | |
| 12 | 565-03-11270 | CUSHION | 1002-@ | |
| 13 | 01010-30820 | BOLT | 1002-@ | |
| 14 | 01602-00825 | WASHER | 1002-@ | |
| 15 | 01580-00806 | NUT | 1002-@ | |
| 16 | 08029-05010 | WIRE | 1002-@ | |
| 17 | 566-06-12770 | WIRE | 1002-1052 | |
| 18 | 566-06-12460 | WIRE | 1002-@ | |
| 19 | 567-06-12990 | WIRE | 1002-1052 | |
| 20 | 566-06-12960 | HARNESS | 1002-1052 | |
| 21 | 566-06-12370 | WIRE | 1002-1052 |
