| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 566-06-14321 | COMB LAMP ASSEMBLY | ||
| 1 | 08102-02403 | BULB - 3W | ||
| 1 | 08104-12420 | BULB - 25W/10W | ||
| 1 | 08105-12420 | BULB - 25W | ||
| 1 | 566-06-14340 | LENS - RED | ||
| 1 | 566-06-14350 | LENS - ORANGE | ||
| 2 | 566-06-14331 | LAMP ASSEMBLY | ||
| 2 | 08104-12420 | BULB - 25W/10W | ||
| 2 | 566-06-14360 | LENS - RED | ||
| 3 | 566-06-14311 | COMB LAMP ASSEMBLY | ||
| 3 | 08102-02403 | BULB - 3W | ||
| 3 | 08104-12420 | BULB - 25W/10W | ||
| 3 | 08105-12420 | BULB - 25W | ||
| 3 | 566-06-14340 | LENS - RED | ||
| 3 | 566-06-14350 | LENS - ORANGE | ||
| 4 | 08128-22400 | LAMP, BACKUP | ||
| 5 | 736131C2 | ALARM, BACKUP | ||
| 6 | 6132-11-6460 | CAPSCREW - M8 X 1.25 | ||
| 7 | MM0460 | FLAT WASHER - M8 | ||
| 8 | MM0718 | NUT - M8 X 1.25 | ||
| 9 | EF8453 | BRACKET - L.H. | ||
| 10 | EF7824 | BRACKET - R.H. | ||
| 11 | MM0032 | CAPSCREW - M12 X 1.75 X 30 | ||
| 12 | MM0705 | FLAT WASHER - M12 | ||
| 13 | MM0026 | CAPSCREW - M8 X 1.25 X 25 | ||
| 14 | 565-03-011270 | CUSHION | ||
| 15 | MM0022 | CAPSCREW - M8 X 1.25 X 20 | ||
| 16 | MM0704 | FLAT WASHER - M10 | ||
| 17 | MM0178 | NUT - M10 X 1.50 | ||
| 18 | EF8635 | BRACKET, REAR LIGHTS | ||
| 19 | PB9224 | SWITCH, PROXIMITY | ||
| 20 | WA4770 | SCREW, MACHINE - #10 - 24NC X 2" | ||
| 21 | VC5344 | FLAT WASHER - #10 | ||
| 22 | DC3101 | LOCKWASHER - #10 | ||
| 23 | DF0017 | NUT - #10 - 24NC | ||
| 24 | PB9223 | MAGNET ASSEMBLY | ||
| 25 | MM0582 | CAPSCREW - M6 X 1.00 X 20 | ||
| 26 | MM0459 | FLAT WASHER - M6 | ||
| 27 | EF8833 | BRACKET, SWITCH MOUNT | ||
| 28 | EF8835 | BRACKET, SWITCH MOUNT | ||
| 29 | EF8836 | BRACKET, SWITCH MOUNT | ||
| 30 | MM0010 | CAPSCREW - M12 X 1.75 X 25 | ||
| 31 | EF8838 | BRACKET, MAGNET MOUNT | ||
| 32 | MM0579 | CAPSCREW - M6 X 1.00 X 12 | ||
| 33 | MM0176 | NUT - M6 X 1.00 |
