| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | AK8082 | WHEEL - 29" X 57" | ||
| 2 | AK8010 | BAND, BEAD SEAT - 57" | ||
| 3 | AK7741 | RING, SIDE | ||
| 4 | PB6512 | O-RING (1) | ||
| 5 | AK8014 | RING, LOCK | ||
| 6 | PB6621 | SPACER (BETWEEN OUTER & INNER RIM) | ||
| 7 | PB6611 | TUBE | ||
| 7 | PB6610 | TUBE | ||
| 8 | VS5592 | STEM, VALVE SWIVEL - 90 DEG | ||
| 9 | PB2612 | SPUD, COLLIE | ||
| 10 | TZ1016 | RETAINER, WHEEL | ||
| 11 | EB0611 | STUD - 1" - 14UNS X 6" (1) | ||
| 12 | TA2572 | NUT - 1" - 14UNS | ||
| 13 | WA4649 | CLAMP | ||
| 14 | C1601 | CAPSCREW - 3/8" - 16NC X 3/4" | ||
| 15 | C0312 | LOCKWASHER - 3/8" | ||
| 16 | C1547 | FLAT WASHER - 3/8" | ||
| 17 | PB3091 | TUBE | ||
| 18 | WA2670 | CAP, VALVE | ||
| 19 | VJ8012 | HOUSING, CORE | ||
| NS|21 | NOTE: (1) ALSO, SEE REAR BRAKE INSTALLATION PAGE. | |||
| NS|22 | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
