| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 154-30-24210 | PILOT | 1001- | |
| 2 | 154-30-11751 | SPRING | 1001- | |
| 2A | 154-30-24240 | SPRING | 1001- | |
| 3 | 154-30-11222 | ROD | 1001- | |
| 4 | 154-30-24220 | SEAT | 1001- | |
| 5 | 01580-03629 | NUT | 1001- | |
| 6 | 154-30-13320 | LOCK | 1007- | |
| 154-30-11761 | LOCK | 1001-1006 | ||
| 7 | 01010-31225 | BOLT | 1001- | |
| 8 | 01602-01236 | WASHER | 1001- | |
| 9 | 154-30-24230 | STOPPER | 1001- | |
| 10 | 154-30-11141 | CYLINDER | 1001- | |
| 11 | 154-30-13142 | SHAFT | 1007- | |
| 154-30-13141 | ROD | 1001-1006 | ||
| 12 | 154-30-11332 | WASHER | 1001- | |
| 13 | 01010-32050 | BOLT | 1001- | |
| 14 | 154-30-11540 | LOCK | 1001- | |
| 15 | 07000-05070 | O-RING | 1001- | |
| 16 | 01010-31240 | BOLT | 1001- | |
| 16A | 01010-31245 | BOLT | 1001- | |
| 17 | 01602-01236 | WASHER | 1001- | |
| 18 | 195-30-13180 | CAP | 1001- | |
| 19 | 195-30-13191 | LUBRICATOR | 1001- | |
| 19A | 154-30-12320 | COVER | 1001- | |
| 20 | 07020-00000 | FITTING | 1001- | |
| 21 | 154-30-11771 | PISTON | 1001- | |
| 22 | 150-30-13430 | RING | 1001- | |
| 23 | 150-30-13441 | GASKET | 1001- | |
| 24 | 150-30-13470 | RING | 1001- | |
| 25 | 150-30-13480 | RING | 1001- | |
| 26 | 150-30-13460 | RING | 1001- | |
| 154-30-00160 | COVER ASS'Y | 1001- | ||
| 27 | \6\ | COVER | 1001- | |
| 28 | 150-30-13340 | BUSHING | 1001- | |
| 29 | 150-30-13330 | RING | 1001- | |
| 30 | 07020-00000 | FITTING | 1001- | |
| 31 | 07000-05100 | O-RING | 1001- | |
| 32 | 154-30-11191 | COVER | 1001- | |
| 33 | 01010-32055 | BOLT | 1001- | |
| 34 | 01602-02060 | WASHER | 1001- | |
| 35 | 01010-31022 | BOLT | 1001- | |
| 36 | 01602-01030 | WASHER | 1001- | |
| 37 | 154-30-11211 | GASKET | 1001- | |
| 38 | 154-30-11550 | GASKET | 1001- | |
| 39 | 154-30-13330 | SPACER | 1007- |
