| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 101-30-21132 | ARM | 20007-@ | |
| 2 | 07046-03520 | PLUG,EXPANSION | 20007-@ | |
| 3 | 01010-31230 | BOLT | 20007-@ | |
| 4 | 01602-01236 | WASHER,SPRING | 20007-@ | |
| 5 | 101-30-21351 | BOLT | 20007-@ | |
| 6 | 01602-01236 | WASHER,SPRING | 20007-@ | |
| 7 | 101-30-34380 | BOLT | .-30877 | |
| 01090-31275 | BOLT | 20007-. | ||
| 8 | 01582-01210 | NUT | 20007-@ | |
| 9 | 01602-01236 | WASHER,SPRING | 20007-@ | |
| 10 | 101-30-34331 | CYLINDER | 30331-@ | |
| 101-30-34330 | CYLINDER | 24966-30330 | ||
| \3\101-30-34120 | CYLINDER | 20007-24965 | ||
| (101-30-34330{195-30-13190)} | ||||
| 11 | 150-30-13521 | CAP | 20007-24965 | |
| 12 | 101-30-34360 | LUBRICATOR | 30331-@ | |
| 195-30-13190 | LUBRICATOR | 24966-30330 | ||
| 101-30-34260 | LUBRICATOR | 20007-24965 | ||
| 13 | 07020-00000 | FITTING,GREASE | 20007-30330 | |
| 14 | 101-30-21231 | BOX | 20007-30877 | |
| 15 | 101-30-34170 | COVER | 20007-30877 | |
| 16 | 04065-07025 | RING,SNAP | 20007-@ | |
| 17 | 101-30-34140 | SPACER | 20007-@ | |
| 18 | 07016-00558 | SEAL,DUST (KIT) | 20007-@ | |
| 19 | 101-30-34150 | BUSHING | 20007-30877 | |
| 20 | 101-30-34160 | PISTON | 20007-@ | |
| 21 | 04064-02512 | RING,SNAP | 20007-@ | |
| 22 | 101-30-34210 | PACKING | 20007-@ | |
| 23 | 101-30-34220 | RING,PISTON | 20007-@ | |
| 24 | 101-30-34130 | SHAFT | 20007-30877 | |
| 25 | 07020-00675 | FITTING,GREASE | 20007-30877 | |
| 26 | 01010-31435 | BOLT | 20007-30877 | |
| 27 | 01602-01442 | WASHER,SPRING | 20007-30877 | |
| 28 | 101-30-21151 | GASKET (KIT) | 20007-30877 | |
| 29 | 01010-31430 | BOLT | 20007-@ | |
| 30 | 01602-01442 | WASHER,SPRING | 20007-@ | |
| 31 | 04020-01228 | PIN | 20007-@ | |
| 32 | 101-30-21191 | SPRING | 20007-30877 | |
| 33 | 101-30-34350 | SHAFT | .-30877 | |
| \0\101-30-34190 | SHAFT | 20007-. | ||
| 34 | 101-30-11221 | SEAT,SPRING | 20007-30877 | |
| 35 | 01580-02218 | NUT | 20007-30877 | |
| 36 | 101-30-11421 | LOCK | 20007-30877 | |
| 37 | 01010-30816 | BOLT | 20007-30877 | |
| 38 | 01602-00825 | WASHER,SPRING | 20007-30877 | |
| 39 | 101-30-21250 | GASKET | 20007-30877 | |
| 40 | 101-30-21240 | COVER | 20007-30877 | |
| 41 | 01010-31020 | BOLT | 20007-30877 | |
| 42 | 01602-01030 | WASHER,SPRING | 20007-30877 | |
| 43 | 101-30-34370 | COVER | 30331-@ | |
| 44 | 01010-50816 | BOLT | 30331-@ | |
| 45 | 01602-20825 | WASHER,SPRING | 30331-@ |
