| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 175-30-24221 | CYLINDER | 5508-10262 | |
| 2 | 195-30-13180 | CAP | 6091-@ | |
| \0\150-30-13520 | CAP | 5508-6090 | ||
| 3 | \3\195-30-13191 | LUBRICATOR | 8651-@ | |
| (175-30-34160{OR 175-30-34170)} | ||||
| \0\195-30-13190 | LUBRICATOR | 6091-8650 | ||
| \0\150-30-13530 | LUBRICATOR | 5508-6090 | ||
| 3A | 175-30-34160 | STOPPER,L.H. | 8651-@ | |
| 175-30-34170 | STOPPER,R.H. | 8651-@ | ||
| 4 | 07020-00000 | FITTING | 5508-@ | |
| 5 | 170-30-14211 | PISTON | 5508-@ | |
| 6 | 170-30-14230 | RING | 5508-@ | |
| 7 | 175-30-24242 | PACKING | 5508-@ | |
| \0\175-30-24241 | PACKING | 5508-10262 | ||
| 8 | 04064-07525 | RING | 5508-@ | |
| 175-30-00561 | COVER ASS'Y | 5508-10262 | ||
| (\2\175-30-00560) | COVER ASS'Y | (5508-6926) | ||
| 9 | \6\ | COVER | 6927-10262 | |
| \6\ | COVER | 5508-6926 | ||
| 10 | 170-30-14221 | BUSHING | 5508-@ | |
| 11 | 07020-00675 | FITTING | 5508-@ | |
| 12 | 01010-32460 | BOLT | 6091-@ | |
| 01040-32460 | BOLT | 5508-6090 | ||
| 13 | 01602-02472 | WASHER | 5508-@ | |
| 14 | 175-30-34260 | GASKET | 5508-@ | |
| 15 | 175-30-24270 | PLATE | 5508-@ | |
| 16 | 01010-31225 | BOLT | 5508-@ | |
| 17 | 01602-01236 | WASHER | 5508-@ | |
| 18 | 175-30-34140 | PILOT | 5508-@ | |
| 19 | 175-30-34150 | PILOT | 5508-@ | |
| 20 | 175-30-34311 | BOLT | 10263-@ | |
| \0\175-30-34310 | BOLT | 5508-10262 | ||
| 21 | 170-30-14312 | PLATE | 6144-@ | |
| 170-30-14311 | PLATE | 6091-6143 | ||
| 170-30-14310 | LOCK | 5508-6090 | ||
| 22 | 01010-31016 | BOLT | 5508-@ | |
| 23 | 01602-01030 | WASHER | 5508-@ | |
| 24 | 04020-01024 | PIN | 5508-@ | |
| 25 | 175-30-34320 | SLEEVE | 5508-@ | |
| 26 | 175-30-34331 | COVER | 6532-@ | |
| 175-30-34330 | COVER | 5508-6531 | ||
| 27 | 170-30-14341 | GASKET | 5508-@ | |
| 28 | 01010-31230 | BOLT | 6532-@ | |
| 01010-31225 | BOLT | 5508-6531 | ||
| 29 | 01602-01236 | WASHER | 5508-@ | |
| 30 | 170-30-14351 | NUT | 6091-@ | |
| 170-30-14350 | NUT | 5508-6090 | ||
| 31 | 175-30-24360 | PLUG | 5508-10262 | |
| 32 | 07019-00130 | SEAL | 10263-@ | |
| \0\130-09-12760 | SEAL | 5508-10262 | ||
| 33 | 175-30-34180 | SPRING | 5508-@ | |
| 34 | 175-30-34190 | SPRING | 5508-@ | |
| 35 | 175-30-24117 | YOKE | 8651-10262 | |
| \0\175-30-24116 | YOKE | 7190-8650 | ||
| 175-30-24115 | YOKE | 6927-7189 | ||
| 175-30-24114 | YOKE | 6532-6926 | ||
| 175-30-24113 | YOKE | 5508-6531 | ||
| (\2\175-30-24112) | YOKE | (5508-5992) | ||
| 36 | 01010-32095 | BOLT | 6532-@ | |
| 01010-32065 | BOLT | 6091-6531 | ||
| 01040-32065 | BOLT | 5508-6090 | ||
| 37 | 01602-02060 | WASHER | 5508-@ | |
| 38 | 01010-31230 | BOLT | 5508-7189 | |
| 39 | 01640-21223 | WASHER | 5508-7189 | |
| 40 | 01602-01236 | WASHER | 5508-7189 | |
| 41 | 175-30-34210 | SHAFT | 5508-@ | |
| 42 | 01010-31650 | BOLT | 8651-@ | |
| 01010-31650 | BOLT | 6091-8650 | ||
| 01040-31650 | BOLT | 5508-6090 | ||
| 42A | 01010-31655 | BOLT | 8651-@ | |
| 43 | 01602-01648 | WASHER | 5508-@ | |
| 44 | 07000-15090 | O-RING | 5508-@ | |
| 45 | 195-30-14151 | WASHER | 8651-@ | |
| \3\195-30-14150 | WASHER | 5508-8650 | ||
| (195-30-14151{01010-32460(2))} | ||||
| 46 | 01010-32460 | BOLT | 8651-@ | |
| 01010-32450 | BOLT | 6091-8650 | ||
| 01040-32450 | BOLT | 5508-6090 | ||
| 47 | 195-30-14160 | PLATE | 5508-@ | |
| 48 | 175-30-23440 | SPACER | 6532-6926 | |
| 49 | 175-30-34280 | SPACER | 6532-6926 |
