| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07102-20615 | HOSE | 1801-1880 | |
| 2 | 08210-02910 | SPIRAL TUBE | 1829-1880 | |
| 2 | 08210-01810 | SPIRAL TUBE | 1801-1828 | |
| 3 | 04434-52712 | CLIP | 1801-@ | |
| 4 | 01010-81016 | BOLT | 1801-@ | |
| 5 | 01643-31032 | WASHER | 1801-@ | |
| 6 | 07102-20304 | HOSE | 1801-@ | |
| 7 | 21K-62-34560 | ELBOW | 1801-@ | |
| 8 | 07002-12434 | O-RING | 1801-@ | |
| 9 | 144-865-6260 | ELBOW | 1801-@ | |
| 10 | 13S-62-15450 | HOSE, 1220MM | 1801-@ | |
| 11 | 08210-02906 | SPIRAL TUBE | 1829-1837 | |
| 11 | 08210-01806 | SPIRAL TUBE | 1801-1828 | |
| 12 | 04434-53212 | CLIP | 1801-@ | |
| 13 | 01010-81016 | BOLT | 1801-@ | |
| 14 | 01643-31032 | WASHER | 1801-@ | |
| 15 | 07102-20515 | HOSE | 1801-1880 | |
| 16 | 08210-02914 | SPIRAL TUBE | 1829-1880 | |
| 16 | 08210-01815 | SPIRAL TUBE | 1801-1828 | |
| 17 | 22M-977-1150 | CLIP | 1801-@ | |
| 18 | 01010-81016 | BOLT | 1801-@ | |
| 19 | 01643-31032 | WASHER | 1801-@ | |
| 20 | 07102-20516 | HOSE | 1801-1880 | |
| 21 | 08210-02915 | SPIRAL TUBE | 1829-@ | |
| 21 | 08210-01816 | SPIRAL TUBE | 1801-1828 | |
| 22 | 07102-20610 | HOSE | 1801-@ | |
| 23 | 04434-52712 | CLIP | 1801-@ | |
| 24 | 01010-81016 | BOLT | 1801-@ | |
| 25 | 01643-31032 | WASHER | 1801-@ | |
| 26 | 07094-30620 | CLAMP | 1801-@ | |
| 27 | 07095-00630 | CUSHION | 1801-@ | |
| 28 | 01010-81265 | BOLT | 1801-@ | |
| 29 | 01643-31232 | WASHER | 1801-@ |
