| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 205-62-33891 | Hose Assembly | B10001- | |
| 2 | 20Y-62-21720 | Flange | B10001- | |
| 3 | 07000-13048 | O-ring | B10001- | |
| 4 | 01010-81240 | Bolt | B10001- | |
| 5 | 01643-31232 | Washer | B10001- | |
| 6 | 01010-81240 | Bolt | B10001- | |
| 7 | 01643-31232 | Washer | B10001- | |
| 8 | 22U-62-21551 | Clamp | B10001- | |
| 9 | 01010-81225 | Bolt | B10001- | |
| 10 | 01643-31232 | Washer | B10001- | |
| 11 | 07095-01245 | Cushion | B10001- | |
| 12 | 07040-12412 | Plug | B10001- | |
| 13 | 07002-12434 | O-ring | B10001- | |
| 14 | 205-62-33381 | Bracket | B10001- | |
| 15 | 01010-81235 | Bolt | B10001- | |
| 16 | 01643-31232 | Washer | B10001- | |
| 17 | 20Y-62-51251 | Hose | B10001- | |
| 18 | 20Y-62-21720 | Flange | B10001- | |
| 19 | 07000-13048 | O-ring | B10001- | |
| 20 | 01010-81240 | Bolt | B10001- | |
| 21 | 01643-31232 | Washer | B10001- | |
| 22 | 01010-81235 | Bolt | B10001- | |
| 23 | 01643-31232 | Washer | B10001- | |
| 24 | 20Y-62-51332 | Hose | B10001- | |
| 25 | 07000-13032 | O-ring | B10001- | |
| 26 | 07371-31049 | Flange, Split | B10001- | |
| 27 | 07372-21035 | Bolt | B10001- | |
| 28 | 01643-51032 | Washer | B10001- | |
| 29 | 281-01-13180 | Clip | B10001- | |
| 30 | 281-01-13180 | Clip | B10001- | |
| 31 | 01010-81225 | Bolt | B10001- | |
| 32 | 01643-31232 | Washer | B10001- | |
| 33 | 20Y-62-53160 | Flange | B10001- | |
| 34 | 07000-13040 | O-ring | B10001- | |
| 35 | 01010-81035 | Bolt | B10001- | |
| 36 | 01643-31032 | Washer | B10001- |
