| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 154-78-85710 | Bracket | 22001- | |
| 2 | 01010-81225 | Bolt | 22001- | |
| 3 | 01643-31232 | Washer | 22001- | |
| 4 | 154-78-85971 | Bracket | 22001- | |
| 5 | 154-78-85860 | Cushion | 22001- | |
| 6 | 01010-81230 | Bolt | 22001- | |
| 7 | 01643-31232 | Washer | 22001- | |
| 8 | 154-78-85210 | Block | 22001- | |
| 9 | 01010-81230 | Bolt | 22001- | |
| 10 | 01643-31232 | Washer | 22001- | |
| 11 | 17A-78-12160 | Valve | 22001- | |
| 12 | 17A-78-12120 | Flange | 22001- | |
| 13 | 07000-13045 | O-ring | 22001- | |
| 14 | 01252-A1035 | Bolt, Hexagon Socket Head | 22001- | |
| 15 | 01643-51032 | Washer | 22001- | |
| 16 | 02783-10522 | Elbow | 22001- | |
| 17 | 07002-12434 | O-ring | 22001- | |
| 18 | 02896-11015 | O-ring | 22001- | |
| 19 | 07040-13016 | Plug | 22001- | |
| 20 | 07002-13034 | O-ring | 22001- | |
| 21 | 154-78-72211 | Bracket | 22001- |
- Главная
- Каталог запчастей
- Бульдозеры
- D85ex 18 s/n 22001 up
- Hydraulic system
- Ripper piping, cover (#22001 )
