| Item | Part No. | Part Name | Qty | Serial No. |
| (273-70-12000) | ROLLER ASS'Y | 10011- | ||
| THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.3001 AND 3003. | ||||
| 1 | 273-70-11520 | FLANGE,AXLE | 10011- | |
| 2 | 07000-15475 | O-RING | 10011- | |
| 3 | 01010-52055 | BOLT | 10011- | |
| 4 | 01643-32060 | WASHER | 10011- | |
| 5 | 273-70-11640 | RING | 10011- | |
| 6 | 273-70-11570 | RING | 10011- | |
| 7 | 07000-15290 | O-RING | 10011- | |
| 8 | 01010-51035 | BOLT | 10011- | |
| 9 | 01643-31032 | WASHER | 10011- | |
| 10 | 273-70-11510 | HUB | 10011- | |
| 11 | 273-70-11630 | SEAL,OIL | 10011- | |
| 12 | 234-23-12520 | BEARING | 10235- | |
| 06000-32024 | BEARING | 10011-10234 | ||
| 13 | 273-70-00020 | SHIM ASS'Y | 10011- | |
| \6\ | SHIM¤ 0.1MM | 10011- | ||
| \6\ | SHIM¤ 0.5MM | 10011- | ||
| 14 | 273-70-11990 | COVER | 10011- | |
| 15 | 07000-12115 | O-RING | 10011- | |
| 16 | 01010-51035 | BOLT | 10011- | |
| 17 | 273-70-11580 | WASHER | 10011- | |
| 18 | 273-70-11530 | FLANGE | 10011- | |
| 19 | 273-70-11661 | GASKET | 10449- | |
| \0\273-70-11660 | GASKET | 10011-10448 | ||
| 20 | 07011-00150 | SEAL,OIL | 10011- | |
| 21 | 01010-51250 | BOLT | 10011- | |
| 22 | 01643-31232 | WASHER | 10011- | |
| 23 | 273-70-11790 | STOPPER | 10011-10301 | |
| 24 | 273-70-11720 | CUSHION | 10011- | |
| 25 | 273-70-12151 | COVER | 10011- | |
| 26 | 07030-10252 | BREATHER | 10011- | |
| 27 | 01010-51235 | BOLT | 10011- | |
| 28 | 01643-31232 | WASHER | 10011- | |
| 29 | 273-70-11671 | BRACKET,L.H. | 10302- | |
| 273-70-11670 | BRACKET,L.H. | 10011-10301 | ||
| 30 | 273-70-11680 | BRACKET,R.H. | 10011- | |
| 31 | 01010-52070 | BOLT | 10011-10301 | |
| 32 | 01602-22060 | WASHER,SPRING | 10011-10301 | |
| 33 | 01580-12016 | NUT | 10011-10301 | |
| 34 | 01010-51245 | BOLT | 10011- | |
| 35 | 01643-31232 | WASHER | 10011- | |
| 36 | 01580-11210 | NUT | 10011- |
